Manufacturer: Bently Nevada
Product No.: 330173-00-03-10-02-00
Country of origin:United States
Product Type: 3300 5mm Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 100g
Dimensions: 40 mm x 85 mm x 85 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
An M8 x 1 threaded probe body with 0.0 mm unthreaded length (Option 00), a 30 mm case length (Option 03), and a 1.0 m total length lead (Option 10) specifies this unarmored 3300 5mm proximity probe configuration — 330173-00-03-10-02-00. This non-contact eddy-current sensor functions within a compatible transducer chain to measure static position or dynamic shaft vibration of rotating machinery. Because it does not feature stainless steel armor (distinguishing it from the 330174 series) and employs a ClickLoc miniature coaxial connector without an integrated connector protector, it offers a compact physical footprint for small-machinery applications where mounting space is tightly constrained.
The 3300 5mm proximity probe represents a structural improvement with a patented TipLoc molding method that bonds the probe tip securely to the body. This configuration includes a standard, non-armored cable jacket and requires no regulatory approvals (Option 00), facilitating standard installation in non-hazardous industrial zones. It maintains complete electrical compatibility and interchangeability with 3300 5mm-compliant Proximitor sensors and extension cables over the total system length.
| Option / Segment | Code on This SKU | Meaning / Configuration |
|---|---|---|
| Base Model | 330173 | 3300 5mm Proximity Probe, M8 x 1 metric thread, without armor |
| A - Unthreaded Length Option | 00 | 0.0 mm unthreaded length (fully threaded case) |
| B - Overall Case Length Option | 03 | 30 mm overall case length |
| C - Total Length Option | 10 | 1.0 metre (3.3 feet) cable length |
| D - Connector Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 00 | Not required |
| Parameter | Specification / Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model Series | 3300 5 mm Transducer System |
| Part Number | 330173-00-03-10-02-00 |
| Tip Diameter | 5.2 mm (0.21 in) |
| Case Thread Size | M8 x 1 |
| Unthreaded Length | 0.0 mm |
| Overall Case Length | 30 mm |
| Cable Length | 1.0 meter (3.3 feet) |
| Armor Type | Without armor (unarmored FEP jacket) |
| Connector Type | Miniature coaxial ClickLoc connector |
| Linear Range | 2.0 mm (80 mils), begins at 0.25 mm (10 mils) from target |
| Recommended Gap | 1.27 mm (50 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) typical |
| DSL Deviation | Less than +/-0.038 mm (+/-1.5 mil) typical |
| Probe DC Resistance | 7.59 +/- 0.50 ohms (center conductor to outer conductor) |
| Operating Temperature | -35 degC to +177 degC (-31 degF to +350 degF) |
| Frequency Response | 0 to 10 kHz: +0, -3 dB |
| Minimum Target Size | 15.2 mm (0.6 in) diameter (flat target) |
| Cable Bend Radius | 25.4 mm (1.0 in) minimum |
| Recommended Mounting Torque | 5.1 N-m (45 in-lb) typical, 7.3 N-m (65 in-lb) maximum |
Ensure the mounting bracket or hole is drilled and tapped correctly for the M8 x 1 metric thread. The maximum thread engagement length is 12 mm to prevent binding or case damage during installation. Tighten the probe case to the recommended torque of 5.1 N-m (45 in-lb). Do not exceed the maximum torque limit of 7.3 N-m (65 in-lb). The ClickLoc coaxial connector should be mated finger-tight to avoid damage to the gold-plated contacts. Maintain a minimum bend radius of 25.4 mm (1.0 in) for the standard coaxial cable during routing.
