Bently Nevada

Bently Nevada 330854-080-24-00 3300 XL 25 mm Extension Cable

SKU 330854-080-24-00

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330854-080-24-00
  • Origin United States
  • Product Type: 3300 XL 25 mm Extension Cable
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.35 kg
  • Dimensions: 70 mm x 120 mm x 120 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330854-080-24-00 3300 XL 25 mm Extension Cable

Download Open in new tab
Quantity
Call sales Contact

Product Description

Description

Option 080 (8.0 m length), Option 24 (High Temperature FluidLoc cable, unarmored), and Option 00 (no agency approvals) specify this 3300 XL 25 mm Extension Cable configuration — 330854-080-24-00.

This cable acts as the electrical link between a 3300 XL 25 mm proximity probe and a 3300 XL 25 mm Proximitor sensor. Unlike variant option 25 which features stainless steel armor, this option 24 configuration uses a lightweight, unarmored 75 ohm triaxial FluidLoc cable insulated with perfluoroalkoxyethylene (PFA). The FluidLoc technology prevents moisture and process fluids from traversing the cable core, protecting the click-lock coaxial connectors from contamination.

Features

  • 8.0 meter total length (Option 080) matches system calibration when combined with a 1.0 meter probe in a 9.0 meter measurement system.
  • Option 24 configuration features non-armored 75 ohm triaxial FluidLoc cable insulated with perfluoroalkoxyethylene (PFA) for high-temperature service.
  • FluidLoc cable design blocks fluid migration through the internal conductors of the cable assembly.
  • Gold-plated brass and beryllium copper ClickLoc connectors provide stable coaxial contact under mechanical vibration.
  • Option 00 indicates standard commercial construction with no hazardous area approvals.

Applications

  • Large steam turbine generator differential expansion (DE) monitoring
  • Mid-to-large machinery axial shaft position measurements
  • Reciprocating compressor rod-drop monitoring systems
  • Hydroelectric turbine shaft displacement and vibration sensing

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330854-080-24-00 3300 XL 25 mm Extension Cable
A - Cable Length 080 8.0 metres (26.2 feet)
B - Armor and Cable 24 High Temperature FluidLoc cable (no armor)
C - Agency Approval 00 No Approvals

Technical Specifications

Manufacturer Bently Nevada
Part Number 330854-080-24-00
Cable Type 75 ohm triaxial, perfluoroalkoxyethylene (PFA) insulated FluidLoc cable
Length 8.0 metres (26.2 feet)
Core Resistance (Rcore) 2.0 +/- 0.5 ohms (Center conductor to center conductor)
Jacket/Coaxial Resistance (Rjacket) 0.6 +/- 0.2 ohms (Coaxial conductor to coaxial conductor)
Capacitance 69.9 pF/m (21.3 pF/ft) typical
Connector Type Gold-plated brass and gold-plated beryllium copper ClickLoc connectors
Minimum Bend Radius 25.4 mm (1.0 in)
Tensile Strength 270 N (60 pounds) maximum rated at probe lead to extension cable connectors
Torque Specification Recommended finger tight; maximum 0.565 N-m (5 in-lb) connector-to-connector
Operating and Storage Temperature -35 degC to +200 degC (-31 degF to +392 degF)
Humidity Resistance 100% condensing, non-submersible when connectors are protected
Weight 45 g/m (approx. 360 g for 8.0 m cable length)

Connections and Interfaces

Connection Side Connector Type Compatibility
Probe Connection Miniature male coaxial ClickLoc connector Connects to 3300 XL 25 mm proximity probe female connector
Proximitor Connection Miniature female coaxial ClickLoc connector Connects to 3300 XL 25 mm Proximitor sensor male connector

Installation Guidelines

  • Coaxial shielding is isolated from the mounting bracket or panel and must be grounded at the monitor/instrumentation rack.
  • Ensure the fluorosilicone connector protectors are installed over the mated ClickLoc connectors to prevent contamination from dirt and moisture.
  • Maintain the minimum bend radius of 25.4 mm (1.0 inch) during routing to prevent cable strain or internal signal degradation. Avoid running the extension cable alongside high-voltage AC power wiring to prevent electromagnetic interference.
  • Hand-tighten the ClickLoc connectors; do not exceed 0.565 N-m (5 in-lb) of torque.

Compliance and Certifications

  • CE Mark (European Conformity)
  • RoHS compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the option 24 specify on the 330854-080-24-00 extension cable?
Option 24 specifies a high-temperature FluidLoc cable without stainless steel protective armor. This makes it lighter and more flexible than armored options.
What is the total length of the 330854-080-24-00 cable?
Option 080 specifies a cable length of 8.0 metres (26.2 feet). It must be paired with a 1.0-meter probe to match a 9.0-meter system calibration.
Does this extension cable carry hazardous area certifications?
No, the 330854-080-24-00 has the 00 agency approval option, which designates standard commercial construction with no hazardous area approvals.
What is the temperature limit for this 3300 XL 25 mm extension cable?
The cable has an operating and storage temperature rating of -35 degC to +200 degC (-31 degF to +392 degF).
