Bently Nevada 330930-065-05-00 3300 XL NSv Extension Cable

Description

The Bently Nevada 330930-065-05-00 is an electrical connection component designed for the 3300 XL NSv Proximity Transducer System. This Extension Cable provides seamless link continuity between a 3300 NSv proximity probe and a 3300 XL NSv Proximitor Sensor. It features a 6.5-meter cable length with a 5.0-meter system length option and is built with standard coaxial construction without an armored jacket. The system is specifically engineered for machinery with tight installation limits, small target requirements, or counterbore restrictions where standard proximity transducer configurations cannot fit, ensuring clear signaling for radial vibration, axial position, and tachometer measurements.

Features

• Seamless signal coupling between the proximity probe and the Proximitor sensor.
• Coaxial construction optimized for high-frequency eddy current monitoring.
• ClickLoc connectors ensure tight, consistent mechanical and electrical coupling.
• Built-in connection protection options to withstand demanding machinery environments.

Applications

• Centrifugal air compressors
• Refrigeration compressors
• Process gas compressors
• Small shaft radial vibration measurement
• Fluid-filmed bearing machinery monitoring

Ordering Information

Technical Specifications

Installation Guidelines

• Minimum Bend Radius: Do not bend the cable tighter than a 25.4 mm radius to protect the internal coaxial structure.
• Connector Tightening: Finger-tighten the ClickLoc connectors, then use specialized wrenches to torque to a maximum of 0.565 N-m.
• Cable Routing: Route the cable away from high-voltage machinery wiring or transient electrical lines to minimize EMI induction.
• Connector Insulation: Ensure connector protectors are properly installed if the system is exposed to oil or moisture.

Compliance and Certifications

• EMC Directive 2014/30/EU: EN 61000-6-2, EN 61000-6-4.
• RoHS Directive 2011/65/EU: Compliant.
• China RoHS: EFUP 15 years per SJ/T 11364-2024.
• Hazardous Area Approvals: Class I, Zone 0: AEx/Ex ia IIC T4/T5 Ga; Class I, Zone 2: AEx/Ex nA IIC T5...T1 Gc / ec IIC T5...T1 Gc (when used within approved system matching).
