Honeywell 900G02-0102 ControlEdge HC900 16 Channel 24 VDC Digital Input Module

Honeywell 900G02-0102 ControlEdge HC900 16 Channel 24 VDC Digital Input Module

Only 3 item(s) left in stock

  • Manufacturer: Honeywell

  • Product No.: 900G02-0102

  • Country of origin:United States

  • Product Type: Digital Input Modules

  • Payment: T/T, Western Union

  • Weight: 250g

  • Dimensions: 130 mm x 130 mm x 85 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

View full details
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

The Honeywell 900G02-0102 is a 16-channel 24 VDC digital input module designed for the ControlEdge HC900 controller system. It interfaces discrete field signals with the system rack, delivering signal processing and galvanic isolation between chassis ground and input channels.

Each channel on the 900G02-0102 digital input module monitors discrete state changes from field devices and reports channel status to the ControlEdge HC900 CPU or scanner module. An onboard microprocessor conducts parallel signal processing per module to maintain high-speed execution across backplane racks. The device features front-panel LEDs for channel and module diagnostics and interfaces with detachable Euro or Barrier terminal blocks or Remote Termination Panels.

Features

  • Senses 16 discrete 24 VDC digital input channels for process state monitoring
  • Dedicated onboard microprocessor in each module for parallel signal processing
  • Front-panel status indicators for module status and individual channel activity
  • Galvanic isolation between chassis ground and input channels
  • Compatible with Euro style and Barrier style terminal blocks
  • Supports Remote Termination Panel (RTP) wiring assemblies
  • Supports Removal and Insertion Under Power (RIUP) during maintenance procedures

Applications

  • Discrete device state monitoring in process control systems
  • Sequence and safety interlock state sensing in ControlEdge HC900 controller racks
  • Field signal integration for manufacturing unit operations

Ordering Information

Part Number Description SIL Compatible
900G02-0102 Digital Input, 24 VDC (16 channel) No
900G02-0202 Digital Input, 24 VDC (16 channel) - SIL Yes

Technical Specifications

Parameter Specification
Manufacturer Honeywell
Model 900G02-0102
Series ControlEdge HC900
Module Type Digital Input Module
Channels 16
Input Signal 24 VDC
Isolation Galvanic isolation (chassis to input)
Signal Processing Dedicated microprocessor per module
SIL Capability Non-SIL (SIL Compatible: No)
System Compatibility ControlEdge HC900 Controller / Scanner Racks

Connections/Interfaces

Interface Component Description / Specification
Terminal Block Options Euro style (900TEK-0001) or Barrier style (900TBK-0001)
Remote Termination Panel Compatible with RTP (900RTS-0001) via low voltage cable
Module Jumpers Internal jumpers for input circuit configuration

Installation Guidelines

  • Install the module securely into a designated slot in a ControlEdge HC900 controller rack or I/O expansion rack.
  • Route field input wiring using appropriate wire gauges and terminate firmly at the detachable terminal block or RTP cable connector.
  • Maintain shield grounding and wiring separation standards inside cabinet enclosures.
  • Adhere to RIUP safety protocols before inserting or removing modules under power.

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
1746-IV16 Allen-Bradley 1746-IV16 SLC 500 Sourcing DC Input Module Original New In Stock View Details
ADV151-E00 S2 Yokogawa ADV151-E00 S2 CENTUM VP Digital Input Module Original New In Stock View Details
Key Features:
#ControlEdge HC900 #Digital Input Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Honeywell 900G02-0102 ControlEdge HC900 16 Channel 24 VDC Digital Input Module

Download Open in new tab

What is the Honeywell 900G02-0102 used for?
The Honeywell 900G02-0102 is a 16-channel 24 VDC digital input module used to sense discrete field input signals and interface them with the ControlEdge HC900 controller system.

Which system is the module compatible with?
The module is compatible with Honeywell ControlEdge HC900 local controller racks and remote I/O expansion racks.

How many input channels does the device provide?
The device provides 16 discrete 24 VDC digital input channels with galvanic isolation between chassis ground and input circuitry.

What terminal block options are supported by the module?
The module supports Euro style terminal blocks (900TEK-0001), Barrier style terminal blocks (900TBK-0001), and Remote Termination Panels (900RTS-0001).

Is the Honeywell 900G02-0102 SIL rated?
No. Model 900G02-0102 is a non-SIL legacy module, whereas model 900G02-0202 is designated for SIL compatible system configurations.
