ATS48D32Y

Schneider Electric

Schneider Electric ATS48D32Y Altistart 48 Soft Starter

SKU ATS48D32Y

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: ATS48D32Y
  • Origin France
  • Product Type: Soft starters
  • Payment: T/T, Western Union
  • Weight: 7.53 kg
  • Dimensions: 25,5cm x 36,2cm x 28,5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Soft starters
Quantity
Call sales Contact

Product Description

Description

The ATS48D32Y is an Altistart 48 soft starter designed for the controlled starting and stopping of three-phase asynchronous motors. This unit is rated for a nominal current of 27 A and supports a wide supply voltage range from 208 V to 690 V. With a power handling capacity ranging from 5.5 kW to 22 kW, the ATS48D32Y provides a robust solution for reducing mechanical stress and current surges during motor acceleration in diverse industrial applications.

Features

  • Motor Control: Smooth starting and stopping of asynchronous motors to reduce mechanical shock.
  • Supply Voltage: Wide operating range of 208 V to 690 V.
  • Current Rating: 27 A nominal.
  • Power Range: Supports motor power from 5.5 kW up to 22 kW depending on voltage configuration.
  • Series: Altistart 48.

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Altistart
Subrange 48
Model ATS48D32Y
Type of Product Soft Starters
Nominal Current 27 A
Power Rating 5.5 - 22 kW
Supply Voltage 208 - 690 V
Dimensions (LxWxH) 25.5 cm x 36.2 cm x 28.5 cm
Weight 7.53 kg
Product Phase Phase-Out
Commodity Code 84798997

Installation Guidelines

  • Mounting: Ensure the soft starter is installed vertically on a level surface to facilitate optimal heat dissipation.
  • Ventilation: Maintain adequate clearance around the unit as specified in the technical manual to prevent thermal overload.
  • Wiring: Connect the power supply to the input terminals and the motor to the output terminals, ensuring all connections are tightened to the specified torque.
  • Grounding: Always connect the protective earth (PE) terminal to a secure system ground.
  • Configuration: Verify that the supply voltage matches the settings configured in the starter control parameters before commissioning.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the function of the ATS48D32Y?
It is a soft starter used to provide controlled acceleration and deceleration for three-phase asynchronous motors.
What is the voltage and current range for this unit?
The unit operates within a 208-690 V range and has a nominal current rating of 27 A.
What is the lifecycle status of the ATS48D32Y?
The ATS48D32Y is currently in the 'Phase-Out' lifecycle stage.
What is the power range supported by this soft starter?
It supports applications requiring between 5.5 kW and 22 kW, depending on the operational voltage.
