Schneider Electric ATV930D37M3C Altivar 930 Variable Frequency Drive

Description

The ATV930D37M3C is a high-performance Altivar 930 variable frequency drive (VFD) from Schneider Electric, optimized for demanding industrial processes requiring precise motor control. This upright frequency converter is rated for 37 kW and operates on a 200-240 V supply voltage. It is designed for applications where high-level control and connectivity are essential, offering robust performance in a compact, upright enclosure. This model is configured without a brake chopper, making it an efficient choice for applications that do not require regenerative braking capabilities.

Features

• Series: Altivar 930
• Power Rating: 37 kW
• Supply Voltage: 200-240 V
• Protection Rating: IP21
• Configuration: Upright frequency converter; does not include a brake chopper

Applications

• High-inertia machine control
• Industrial process automation
• Pump and fan systems requiring advanced torque control
• Material handling and conveyor systems
• Extrusion and processing machinery

Technical Specifications

Installation Guidelines

• Mounting: Designed as an upright unit. Given the weight of 59.40 kg, utilize appropriate lifting equipment and ensure the mounting structure is fully reinforced to support the load.
• Environment: Operate within a clean, climate-controlled cabinet environment to maintain internal component integrity. Ensure sufficient clearance for airflow, as the unit dissipates heat during high-load operations.
• Wiring: Connect the 3-phase power input and motor cables using appropriately sized conductors for the 37 kW load. Ensure all power connections are torqued to specifications provided in the manual.
• Grounding: A robust earth connection is mandatory. Securely bond the drive chassis to the system ground bus to ensure electrical safety and compliance with noise immunity standards.
• Cooling: Verify that the installation area provides adequate air intake and exhaust. If installed in a closed enclosure, ensure cooling systems are rated for the heat dissipation requirements of a 37 kW drive.
