BECKHOFF C6015-0010 Ultra-Compact Industrial PC

Description

Designed for space-constrained control cabinet installations, the BECKHOFF C6015-0010 delivers high-performance processing in an exceptionally small footprint. This ultra-compact industrial PC leverages Intel Atom processors to execute demanding automation, visualization, and communication tasks directly at the machine level. Its robust, fanless design ensures long-term reliability in harsh industrial environments, making it an ideal hardware platform for TwinCAT-based control systems.

Featuring an aluminum zinc die-cast housing, the device is engineered for passive cooling via a single-side cooling plate. With dual on-board Gigabit Ethernet interfaces and versatile USB connectivity, the C6015-0010 integrates seamlessly into modern industrial networks, serving as an efficient edge gateway, controller, or decentralized data acquisition node.

Features

• Extremely compact form factor optimized for space-saving control cabinet installation.
• Robust aluminum zinc die-cast housing for enhanced mechanical durability.
• Passive cooling design utilizing a single-side cooling plate for maintenance-free, fanless operation.
• Dual on-board Gigabit Ethernet ports for high-speed network communication and OT/IT integration.
• Flexible mounting configurations including rear-wall, side-wall, or DIN rail installation.
• Dedicated M.2 SSD slot for reliable, solid-state storage.

Applications

• Machine control and decentralized automation systems
• Industrial Internet of Things (IIoT) gateways and edge computing
• Data acquisition, logging, and protocol conversion
• Building automation and infrastructure monitoring systems

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Secure the device using the standard rear-wall mounting sheet. Ensure the mounting surface is flat and stable. Optional side-wall or DIN rail mounting kits must be used in accordance with Beckhoff specifications.
• Cooling & Clearance: To maintain passive thermal dissipation, a minimum free space of 5 cm (2 inches) is strictly required above and below the PC. Do not block the air circulation path around the cooling plate.
• Power Connection: Connect to a stabilized 24 V DC power supply. Ensure proper grounding of the housing to prevent electromagnetic interference (EMI) and protect internal components.
• Environmental Conditions: Operate only within the specified temperature range of 0 to 55 degC. Avoid installation in environments with high humidity, conductive dust, or corrosive gases.
