CP3921-0010 | BECKHOFF | Panneau de commande multi-touch avec CP-Link 4

Description

Designed for mounting arm installation, the CP3921-0010 control panel integrates Beckhoff's high-performance visualization interface with a wide-format multi-touch display. This unit features complete IP65 protection, housing a 21.5-inch screen within a durable, fanless aluminum enclosure with an integrated glass front. Engineered to withstand harsh industrial environments, it provides reliable operator control and monitoring directly at the machine.

By employing CP-Link 4 connection technology, this control panel can operate at distances of up to 100 meters from the host industrial PC. This interface transmits DVI, USB 2.0 (running at 100 Mbit/s), and power via a single standard Cat.6A cable, simplifying installation and reducing wiring overhead. Mechanical installation is supported by a robust mounting arm adapter that accommodates standard 48 mm tube systems, allowing both rotatable and tiltable configurations from either the top or bottom of the housing.

Features

• Widescreen 21.5-inch multi-finger touch display with a resolution of 1920 x 1080 pixels.
• Projected capacitive touch (PCT) technology for precise multi-touch and gesture operation.
• Integrated CP-Link 4 interface, supporting One Cable Technology (OCT) for data and power transmission.
• Operational range up to 100 meters between the control panel and transmitter module.
• All-round IP65 ingress protection rated for protection against dust and low-pressure water jets.
• Double M12 round connectors ensuring secure, IP65-rated industrial physical interfaces.
• Passive cooling design in an aluminum housing to optimize heat dissipation.

Applications

• Heavy machinery and production line visualization.
• Automotive manufacturing assembly stations.
• Process automation in food, beverage, and chemical processing facilities.
• Industrial monitoring stations requiring high-resolution wide-screen displays.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mount the unit using a compatible 48 mm tube mounting arm system. Ensure all four M6 bolts are tightened to the specified torque.
• Utilize high-quality Cat.6A cables for the CP-Link 4 connection to guarantee signal integrity up to 100 meters.
• Ensure the minimum bend radius of the Cat.6A and power cabling is respected inside the mounting arm joints.
• Maintain sufficient clear air space around the rear aluminum cooling fins to allow natural convection and prevent thermal build-up.

Compliance and Certifications

• CE
• UL (referenced under industrial control equipment standards)
