CP7702-0020-0050 | BECKHOFF | Écran 15 pouces 1024 x 768

Description

Operating as an integrated industrial control and visualization terminal, the CP7702-0020-0050 panel PC combines a high-resolution 15-inch display with compact processing power. This resilient hardware unit is engineered for mounting-arm installation directly on machines or control consoles, eliminating the need for separate control cabinets. Its robust design features an aluminum housing with all-round IP65 protection, enabling reliable operation in demanding factory-floor environments.

Equipped with an Intel Atom processor, the CP7702-0020-0050 handles local control tasks, HMI visualization applications, and complex automation workflows within Beckhoff TwinCAT execution environments. The display provides a crisp 1024 x 768 resolution, backed by industrial-grade touch-screen options for interactive operation. Connectivity is established via dual Gigabit Ethernet ports and a rugged IP65-rated DIN 12-pin RS232 interface, ensuring secure data exchange and seamless fieldbus integration.

Features

• Robust, fully enclosed aluminum housing with IP65 ingress protection.
• Brilliant 15-inch display with a resolution of 1024 x 768 pixels.
• Efficient Intel Atom x5-E3930 or x5-E3940 processing options.
• Flexible touch options, including single-finger touch screens, touch pads, or front laminates without keys.
• Dual 10/100/1000BASE-T Ethernet interfaces with IP65 physical connectors.
• Integrated RS232 serial port available via a backplane DIN 12-pin IP65 interface.

Applications

• Machine-level visualization and operation in manufacturing plants.
• HMI and local PLC execution in automotive assembly lines.
• Process monitoring and control in food processing and packaging plants.
• Material handling and distribution system management.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Mount the unit securely using the four M6 x 18 mm threaded holes located in the backplane adapter. Ensure the mounting arm can safely support the 9 kg structural load.
• Cooling: Install the device with adequate spacing around the housing to facilitate passive heat dissipation. Do not block air circulation.
• Cable Routing: Use specified IP65 connectors and sealed cable glands to maintain the ingress protection rating. Route signal cables away from high-power AC cables to prevent electromagnetic interference.
• Grounding: Ensure the aluminum housing is properly grounded to the machine frame or system ground to protect against electrostatic discharge and electric noise.
