Minuterie numérique Omron H5CX-AS-N

Description

The H5CX-AS-N is a high-performance digital timer from Omron’s H5CX-A series. Designed for flexibility and reliability in industrial automation, this standard-type timer features a highly legible, multi-color display (red, green, or orange) and supports a wide variety of timing functions to accommodate complex control sequences.

This model is built with a user-friendly interface that includes DIP switch settings for quick configuration, and it offers both Timer Mode (11 modes) and Twin Timer Mode (4 modes). It is highly versatile in its signal handling, supporting both NPN and PNP inputs as well as gate input, allowing it to be easily integrated into diverse control architectures. It operates on a wide range of power supplies, including 100 to 240 VAC or 24 VAC/12 to 24 VDC, and is designed for secure mounting via a screw terminal block.

Features

• Series: H5CX-A Standard type
• Operating Modes: 11 Timer modes and 4 Twin Timer modes
• Input Flexibility: Supports both NPN and PNP input signals
• Display: Multi-color present value display (Red, Green, Orange)
• Configuration: Easy setup via physical DIP switches
• Power Supply: Wide range (100–240 VAC or 24 VAC/12–24 VDC)
• Design: Compact unit with secure screw terminal connections

Applications

• Automated assembly line timing sequences
• Industrial machine process control
• Conveyor system interval management
• HVAC system cycling and sequencing
• Laboratory equipment and testing procedures

Technical Specifications

Installation Guidelines

• Panel Mounting: Ensure the timer is mounted in a panel cutout with sufficient space for the locking bracket to securely hold the unit against the panel wall.
• Wiring Configuration: Use the DIP switches on the side or rear of the unit to define the timer range and operating mode before applying power to the device.
• Input Signal Logic: Verify that your system output (NPN or PNP) matches the input wiring configuration of the H5CX-AS-N to ensure proper trigger activation.
• Environmental Considerations: Keep the device away from areas with high vibration or excessive electromagnetic noise, as these can interfere with the internal timing circuits.
