Siemens 6SL3120-1TE21-8AB0 Module moteur unique SINAMICS

Description

The Siemens 6SL3120-1TE21-8AB0 is a Single Motor Module from the SINAMICS S120 drive family. It is a high-performance power component designed to drive a single motor by converting a DC link voltage into a three-phase AC output. With a nominal DC input of 600 V and an output of 18 A at 400 V, this module is optimized for motion control tasks requiring precision, high dynamic response, and energy efficiency. It utilizes internal air cooling and includes a DRIVE-CLiQ interface for seamless, high-speed communication with the Control Unit.

Features

• High Performance: Designed for demanding multi-axis and single-axis drive applications.
• Thermal Management: Integrated internal air cooling system for reliable heat dissipation.
• Communication: Includes DRIVE-CLiQ cable for intelligent, standardized connectivity within the SINAMICS ecosystem.
• Durability: Features a painted finish, providing enhanced environmental protection.
• Integration: Compact modular design for space-saving installation in control cabinets.

Applications

• Multi-axis machine tools
• Packaging and printing machinery
• Industrial production line motion control
• High-precision positioning systems

Technical Specifications

Installation & Integration Guidelines

• Mounting: Install the module in a vertical orientation within a suitable control cabinet. Ensure the cooling air intake and exhaust vents are not obstructed.
• Wiring: Use screened power cables to minimize electromagnetic interference (EMI). Connect the DRIVE-CLiQ cable to the corresponding interface on the Control Unit.
• DC Link: Ensure the DC link busbars are securely connected to the Line Module to facilitate power distribution.
• Thermal Clearances: Maintain the minimum clearance distances above and below the module as specified in the Siemens SINAMICS S120 documentation to ensure optimal thermal performance.
