BECKHOFF CP3912-0000 Multi-touch Control Panel

SKU CP3912-0000

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CP3912-0000
Origin Germany
Product Type: Industrial Control Panels
Payment: T/T, Western Union
Weight: 0.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF CP3912-0000 is a multi-touch control panel engineered with an advanced aluminum housing and a durable glass front designed for industrial machine-level operation. As part of the CP39xx series, this operator interface integrates a multi-finger touch screen paired with a DVI/USB Extended interface, allowing the unit to be installed at a distance of up to 50 meters from the host industrial PC.

This control panel supports reliable remote visualization and operator control tasks in demanding factory automation environments. It communicates via DVI-E and USB-E 2.0 technologies, ensuring high-speed transmission of video data and USB signals over extended cable lengths without requiring local processing hardware at the panel.

Features

12-inch multi-finger touch screen display with an 800 x 600 resolution
Robust aluminum housing equipped with a continuous glass front and IP65 protection rating
DVI-E and USB-E 2.0 interface technology enabling remote PC connection up to 50 m away
Compatible with standard DVI PC outputs and supports USB 2.0 data rates up to 480 Mbit/s
IP65-rated connectors for secure ingress protection at the connection block
Designed for 24 V DC industrial power supply inputs

Applications

Machine tool monitoring and operator control stations
Automated manufacturing and assembly line visualization
Packaging and material handling system interfaces
Process control and remote industrial PC operator terminals

Technical Specifications

General

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	CP3912-0000
Product Type	Multi-touch Control Panel
Housing Material	Aluminum housing with glass front
Country of Origin	Germany

Display and Touch Screen

Parameter	Specification
Display Size	12 inch
Resolution	800 x 600
Touch Screen Type	Multi-finger touch screen

Electrical and Interfaces

Parameter	Specification
Power Supply	24 V DC
Connection Technology	DVI-E and USB-E 2.0
Transmission Distance	Up to 50 m
Data Rate	Up to 480 Mbit/s (USB-E 2.0)

Mechanical and Environmental

Parameter	Specification
Protection Rating	IP65
Operating Temperature Range	0 to 55 degC
Mounting Options	4 M6 threaded holes (100 x 100 mm spacing), rotatable and tiltable mounting arm adapter for 48 mm tubing

Installation Guidelines

Verify that the exact model CP3912-0000 and all supplied components match your system engineering requirements before beginning installation.
Ensure all associated power supplies and connected industrial PCs are fully de-energized and locked out prior to handling cables or mounting hardware.
Inspect the aluminum housing, glass front, seals, and IP65 connectors for any signs of transit damage.
Mount the control panel using the rear M6 threaded holes or attach it to a compatible 48 mm mounting arm system from the top or bottom via the rotatable and tiltable adapter.
Connect the DVI-E and USB-E 2.0 cables, ensuring the IP65-rated connectors are firmly seated and tightened to maintain environmental sealing.
Connect the 24 V DC power supply to the unit, verifying correct polarity and voltage levels before energizing the system.
Power on the remote industrial PC and test touch functionality and display clarity during initial commissioning.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the maximum transmission distance for the BECKHOFF CP3912-0000?

The BECKHOFF CP3912-0000 multi-touch control panel utilizes DVI-E and USB-E 2.0 interface technology to connect remotely to a host industrial PC. This advanced transmission capability allows the operator interface to be mounted up to 50 meters away from the main processing hardware. Consequently, it provides flexible installation options for large manufacturing cells and sprawling industrial automation systems.

What display specifications does this industrial control panel feature?

The BECKHOFF CP3912-0000 features a 12-inch multi-finger touch screen display engineered with an 800 x 600 pixel resolution. It is housed in a robust aluminum enclosure paired with a continuous glass front to withstand harsh factory floors. Furthermore, the entire assembly maintains an IP65 protection rating against dust and water ingress.

What are the power supply and electrical requirements for the CP3912-0000?

The BECKHOFF CP3912-0000 requires a standard 24 V DC industrial power supply input for reliable operation. The unit supports high-speed USB 2.0 data transmission rates up to 480 Mbit/s over the extended connection cables. Proper polarity and voltage verification are essential during installation to prevent damage to the internal electronics.

How is the BECKHOFF CP3912-0000 mounted in an industrial environment?

The BECKHOFF CP3912-0000 offers versatile mounting options utilizing four M6 threaded holes with a 100 x 100 mm spacing on the rear. Additionally, integrators can attach the panel using a rotatable and tiltable mounting arm adapter designed for standard 48 mm tubing. This mechanical flexibility ensures ergonomic positioning for machine tool monitoring and operator control stations.
