BECKHOFF EPP2008-0002 EtherCAT P Box

SKU EPP2008-0002

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: EPP2008-0002
Origin Germany
Product Type: EtherCAT P Box
Payment: T/T, Western Union
Weight: 0.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

The EPP2008-0002 is a robust 8-channel digital output EtherCAT P Box from BECKHOFF, specifically designed for distributed control applications where space and wiring efficiency are critical. By integrating the EtherCAT communication protocol with 24 V DC power delivery in a single P-coded M8 connection, this module significantly reduces cabling overhead. Housed in an IP65/66/67-rated enclosure, it provides high-performance output switching for industrial actuators, lamps, and inductive loads in harsh, field-level environments.

Features

8 digital output channels for 24 V DC load switching
EtherCAT P bus interface via 2 x P-coded M8 sockets
Individually short-circuit proof outputs (0.5 A per channel)
Suitable for ohmic, inductive, and lamp loads
Fast switching times (typ. 50 µs TON / 100 µs TOFF)
Rugged IP65/66/67 protection for direct machine mounting
Compact, lightweight design (approx. 165 g)

Applications

Distributed actuator control in automotive or assembly lines
Harsh-environment signaling and lighting control
Modular machine automation requiring single-cable power and data
Robotic cells and end-of-arm tooling control

Technical Specifications

Category	Specification
Manufacturer	BECKHOFF
Model	EPP2008-0002
Protocol	EtherCAT
Number of Outputs	8
Output Connection	M12 x 1, 5-pin, a-coded
Max. Output Current	0.5 A per channel
Load Voltage	24 V DC (-15 %/+20 %)
Electrical Isolation	500 V
Operating Temperature	-25 to +60 degC
Storage Temperature	-40 to +85 degC
Protection Rating	IP65/66/67
Weight	approx. 165 g

Connections/Interfaces

Interface Type	Function
P-coded M8 (2x)	EtherCAT P bus communication and power supply
A-coded M12 (8x)	Digital output signal interface

Installation Guidelines

Mount the device securely using the integrated mounting points on a stable, vibration-resistant surface.
Use P-coded M8 connectors for EtherCAT P to ensure reliable power and data transmission.
Ensure that all unused ports are properly capped and active M12 connectors are tightened to maintain the IP65/66/67 rating.
Keep the total load current within the design limits to ensure the short-circuit protection features operate effectively.
Observe ambient temperature limits (-25 to +60 degC) to prevent thermal degradation during continuous high-load operation.

Compliance and Certifications

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary benefit of the EtherCAT P interface on this module?

EtherCAT P allows for both EtherCAT communication and 24 V DC power to be transmitted over a single cable, reducing wiring requirements.

What types of loads can the EPP2008-0002 outputs switch?

The outputs are capable of switching ohmic, inductive, and lamp loads.

Are the outputs protected against overcurrent?

Yes, each channel is individually short-circuit proof with a short-circuit current of typ. 1.5 A.

What is the IP rating of this device?

It is rated IP65/66/67, ensuring high protection against dust and water ingress.
