330104-02-12-50-02-00: 3300 XL 8 mm proximity probe with M10 x 1 metric thread and protective stainless steel armor, specifying Option 02 (20 mm unthreaded length), Option 12 (120 mm overall case length), Option 50 (5.0 m total length), Option 02 (miniature coaxial ClickLoc connector, standard cable), and Option 00 (no agency approvals required).
This specific configuration features an integrated stainless steel armor sleeve over the 5.0-meter cable to safeguard against mechanical wear, abrasion, and debris in industrial environments. Calibrated for 5.0-meter total system length, the probe must pair directly with a 5-meter Proximitor sensor (without an extension cable) or another compatible configuration to perform non-contact shaft vibration and axial position measurements on critical rotating machinery.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Base Model | 330104 | 3300 XL 8 mm Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length | 02 | 20 mm unthreaded length (ordered in increments of 10 mm) |
| B - Overall Case Length | 12 | 120 mm overall case length (ordered in increments of 10 mm) |
| C - Total Length | 50 | 5.0 meters (16.4 feet) total cable length (requires 5-meter Proximitor sensor) |
| D - Connector/Cable Type | 02 | Miniature coaxial ClickLoc connector, standard cable (no connector protector) |
| E - Agency Approval | 00 | No hazardous area approvals required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-02-12-50-02-00 |
| Product Family | 3300 XL 8 mm Proximity Transducer System |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Thread Size | M10 x 1 |
| Unthreaded Length | 20 mm (0.79 in) |
| Case Length | 120 mm (4.72 in) |
| Total Length | 5.0 meters (16.4 feet) |
| Cable Type | Standard coaxial cable with stainless steel armor sleeve |
| Connector | Miniature coaxial ClickLoc male connector |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Differential Pressure Sealing | Up to 7.0 bar (100 psi) between tip and case (O-ring sealed) |
| Target Material Compatibility | AISI 4140 steel (standard calibration target) |
| Linear Range | 2.0 mm (80 mils), typically starting at 0.25 mm (10 mils) from the probe tip |
| Scale Factor | 7.87 V/mm (200 mV/mil) when properly paired |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) (coiled packaging reference) |
| Weight | 0.50 kg |
Ensure that the probe case M10 x 1 threads are properly engaged without exceeding the maximum recommended torque to avoid thread binding. Maintain an appropriate gap within the linear range of the transducer system (typically 1.27 mm or 50 mils for mid-range calibration). Since this probe has a 5.0-meter integral cable, connect it directly to a 5-meter Proximitor sensor without using an extension cable. Lay out the armored cable with a minimum bend radius of 25.4 mm (1.0 in) to prevent damage to the inner coaxial core.
This product configuration is certified to comply with general electrical and manufacturing standards. Option 00 specifies that no hazardous area or explosion-proof certifications are included or active on this specific probe configuration.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-02-12-50-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 500g
Dimensions: 150 mm x 150 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
