Delta Electronics VFD185E43A VFD-E Variable Frequency Drive

SKU VFD185E43A

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Delta Electronics
Product No.: VFD185E43A
Origin United States
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 7.47 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Control and regulation of three-phase asynchronous motor speeds is handled efficiently by the VFD185E43A variable frequency drive, a core component of the modular Delta Electronics VFD-E Series. Engineered for low-horsepower, high-performance industrial applications, this drive delivers a maximum applicable motor output of 18.5 kW (25 HP). Its physical architecture features a highly adaptable modular design that supports standard extension cards for I/O functions and fieldbus communications, allowing integration into diverse distributed control topologies.

The unit features built-in PLC functionality, allowing users to write and execute basic ladder logic programs directly within the drive. With an integrated RS-485 interface supporting the Modbus protocol, the VFD185E43A establishes robust communication links with PLC systems, HMIs, and supervisory networks. The physical chassis is designed with forced fan cooling and an IP20 protection rating to withstand industrial control panel environments.

Features

Built-in basic PLC functionality enables standalone sequencing and local control operations without an external controller.
Modular extension architecture supports options for fieldbus communication modules (including DeviceNet, Profibus, and CANopen) and additional I/O expansion.
Removable keypad module allows remote mounting on cabinet doors for convenient parameter access.
Flexible control modes including V/f control and Sensorless Vector Control (SVC) for precise torque and speed management.
Comprehensive protective features: Overcurrent, overvoltage, undervoltage, overheating, motor overload, and ground fault protection.
Side-by-side installation capability optimizes physical space within control enclosures.

Applications

Material handling systems, including conveyor networks and sorting equipment.
HVAC systems for fan, blower, and compressor control.
Water and wastewater treatment infrastructure, specifically centrifugal and dosing pumps.
Woodworking machinery and light packaging equipment.
Textile processing machines requiring precise speed synchronization.

Technical Specifications

ParameterSpecification

Manufacturer	Delta Electronics
Model / Part Number	VFD185E43A
Series	VFD-E
Max. Applicable Motor Output	18.5 kW (25 HP)
Mains Input Voltage	Three-phase 460V AC (380V to 480V AC, 50/60 Hz)
Cooling Method	Forced Fan Cooling
Control Method	V/f Control, Sensorless Vector Control (SVC)
Communication Interface	RS-485 (Modbus ASCII/RTU protocol)
Enclosure Rating	IP20
Net Weight	7.47 kg

Connections and Interfaces

Terminal Group	Terminal Label	Function Description
Main Power Terminals	R/L1, S/L2, T/L3	AC line voltage inputs (3-phase)
	U/T1, V/T2, W/T3	Variable frequency AC output to motor
	PE	Protective Earth / Ground connection
Analog I/O	+10V, AVI, ACM	Analog voltage input (0 to 10V DC) for speed reference
Analog I/O	ACI, ACM	Analog current input (4 to 20mA DC) for speed reference
Digital Inputs	MI1 to MI6	Multi-function digital inputs (programmable)
Digital Inputs	DCM	Common digital signal reference ground
Outputs & Communication	RA, RB, RC	Multi-function relay output (SPDT contact)
Outputs & Communication	SG+, SG-	RS-485 serial communication terminals

Installation Guidelines

Mounting Orientation: Install the drive vertically on a flat, non-flammable vertical surface (such as a metal panel) to ensure proper natural convection.
Clearance Requirements: Maintain a minimum clearance of 50 mm on both sides and 120 mm above and below the drive to prevent heat accumulation.
Grounding: Connect the PE terminal to a dedicated, low-impedance ground point. Do not loop ground connections with other high-current devices.
Wiring Isolation: Route main power cabling (R/L1, S/L2, T/L3) and motor cabling (U/T1, V/T2, W/T3) away from low-voltage control and communication cables to avoid electromagnetic interference.
Environmental Conditions: Ensure the installation environment is free of conductive dust, corrosive gases, and direct exposure to moisture. Operating temperature should not exceed 50 degC without derating.

Compliance and Certifications

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the rated power capacity of the Delta VFD185E43A?

The VFD185E43A variable frequency drive is rated for a maximum applicable motor output of 18.5 kW, which corresponds to 25 Horsepower (HP).

What input voltage range does this drive support?

This model is designed for a three-phase mains input voltage of 460V AC, with a permissible operating range of 380V to 480V AC at 50/60 Hz.

Does the VFD185E43A include an integrated PLC function?

Yes, as part of the VFD-E series, this drive features a built-in PLC function that supports programming and local logic execution without requiring an external control module.

How is the thermal dissipation managed in this drive?

The VFD185E43A utilizes forced fan cooling to manage heat dissipation during heavy-duty operation.

What communication options are natively supported?

It features an integrated RS-485 port supporting standard Modbus ASCII and RTU protocols, and can be expanded with optional card modules for fieldbus protocols such as CANopen or DeviceNet.
