The VFD055E43A (VFD 055E43A) is a high-performance, sensorless vector control AC drive belonging to Delta's versatile VFD-E series. Engineered for a 5.5 kW (7.5 HP) motor capacity, this standard version drive operates on a 460 V three-phase input, making it a staple in industrial power systems. In heavy-duty applications such as textile machinery, wastewater treatment pumps, and conveyor systems, the VFD055E43A provides superior torque control and precise speed regulation. Its modular design allows for flexible extension through optional fieldbus cards, while the integrated PLC functionality enables users to execute simple logic sequences, effectively reducing the need for external controllers and minimizing system footprint.
The VFD055E43A architecture is built around a "Micro" design philosophy that does not compromise on power. As a standard "A" version drive, it features a built-in EMI filter (for specific regions) and an integrated RFI switch for noise suppression. The drive utilizes advanced Fan Cooling to maintain optimal thermal performance during continuous operation. One of its most significant technical advantages is the side-by-side installation capability, facilitated by its high-efficiency heat dissipation system, which saves valuable cabinet space. The unit supports multiple communication protocols and features a modular I/O extension system, allowing for the addition of relay cards, encoder feedback, or analog expansion as required by the specific automation task.
| Feature | Specification |
| Model | VFD055E43A |
| Brand | Delta |
| Series | VFD-E (Sensorless Vector Control) |
| Motor Capacity | 5.5 kW / 7.5 HP |
| Input Voltage | Three-Phase 460 VAC (380 V to 480 V) |
| Output Frequency | 0.1 to 600 Hz |
| Control Mode | V/f Control, Sensorless Vector Control (SVC) |
| Overload Capacity | 150 percent of rated current for 60 seconds |
| Cooling Method | Forced Air Cooling (Fan) |
| Integrated PLC | 500 Steps |
| Protection Rating | IP20 |
| Weight | 4.2 kg (6 kg shipping weight) |
| Dimensions | Standard VFD-E Frame Size (approx. 130 mm x 250 mm x 170 mm) |
Can the VFD055E43A handle high-starting torque applications?
Yes. With its Sensorless Vector Control (SVC) mode, the drive can provide significant starting torque (up to 150 percent at 1 Hz), making it suitable for loads that are difficult to start, such as loaded conveyors or mixers.
Does this drive require an external PLC for simple automation logic?
The VFD055E43A features a built-in PLC with a 500-step capacity. This allows users to program basic timing, interlocking, and sequence logic directly within the drive using Delta’s software, often eliminating the need for a small external PLC.
How is the "Standard Drive" version different from specialized versions?
The "A" suffix denotes the standard hardware configuration, which includes the basic I/O and standard interface. It is the most versatile model, suitable for the vast majority of industrial speed control applications without needing specialized firmware.
Side-by-Side Mounting: The VFD-E series supports high-density mounting. When installing multiple units, ensure the ambient temperature does not exceed 40 deg C for side-by-side configurations. If the temperature is higher, maintain at least a 50 mm gap between drives or provide supplemental cabinet cooling.
Harmonic Mitigation: For 460 V applications, especially in facilities with sensitive electronics, it is highly recommended to install an AC line reactor at the input of the VFD055E43A. This reduces harmonic distortion back to the mains and protects the drive's DC bus capacitors from voltage surges.
Grounding and EMI: Ensure the drive is grounded to a common star point. The motor cable should be shielded, and the shield should be grounded at both the drive and the motor end to minimize radio frequency interference (RFI) that could impact nearby sensor signals.
Global Express Shipping
Returns & Warranty
Manufacturer: Delta Electronics
Product No.: VFD055E43A
Country of origin:United States
Product Type: VFD-E Variable Frequency Drive
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
