Delivering regulated, highly reliable power distribution within the Experion C300 controller subsystem, the Honeywell CC-PWRR01 functions as a dual-channel redundant power source designed to protect critical process control loops from input line failures. This module integrates directly into the Series C power carrier assemblies, allowing for seamless load-sharing, active diode auctioning, and uninterrupted power handovers. Engineered specifically to meet the high-availability demands of modern continuous process environments, the Honeywell CC-PWRR01 stabilizes system voltages, filters electromagnetic interference, and provides real-time diagnostic status feedback directly to the controller architecture.
| Parameter | Value / Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | CC-PWRR01 |
| System Compatibility | Experion C300 / Series C I/O |
| Output Voltage | 24 VDC nominal |
| Configuration | Redundant (requires matching module on compatible carrier) |
| Cooling Method | Natural convection |
| Operating Temperature | 0 to 60 degC (32 to 140 degF) |
| Storage Temperature | -40 to 85 degC (-40 to 185 degF) |
| Relative Humidity | 5% to 95% non-condensing |
| Country of Origin | United States / Global OEM sites |
| Shipping Weight (Calculated) | 2.00 kg (4.41 lbs) |
| Package Dimensions (Calculated) | 250 x 180 x 120 mm (9.84 x 7.09 x 4.72 in) |
| Connection Point | Function / Circuit Assignment |
|---|---|
| Backplane Connector | High-current blind-mate interface interfacing directly with the power carrier bus bars. |
| Status LED Array | Visual indicators for Input OK (Green), Output OK (Green), and Module Fault/Over-Temp (Red). |
The CC-PWRR01 is designed specifically for insertion into the CC-PWRB01 (or equivalent) redundant power carrier. When performing system upgrades or migrations from legacy Experion platforms, verify that your existing carrier backplane is rated to accept Series C Form-Factor modules, as keying pins prevent physical mismating with non-compatible I/O racks.
To guarantee optimal MTBF, maintain at least 50mm of clear space above and below the power carrier assembly to allow unobstructed convective airflow. In highly enclosed or non-ventilated field cabinets, thermal concentration can cause premature aging of the internal electrolytic capacitors. Always implement external ambient monitoring within the cabinet to ensure temperatures do not exceed the 60 degC threshold.
When bringing a redundant pair online, energize the primary and secondary power sources from isolated feed breakers. This layout ensures that an upstream breaker trip on Feed A does not compromise Feed B. Utilize the dry-contact alarm terminal block on the redundant carrier to route power fail status signals back to your diagnostic alarm logs in Experion PKS.
