The FC-CPCHAS-0002 is a high-integrity controller chassis engineered for Honeywell Safety Manager (SMS) and Experion PKS environments. Serving as the core physical and electrical infrastructure, this 4 HE rack-mountable unit houses and provides a redundant backplane for Control Processor (CP) modules.
By supporting dual control processor configurations, the FC-CPCHAS-0002 facilitates Advanced Redundancy Technology (A.R.T.) and Quadruple Modular Redundancy (QMR) to enable SIL 3 safety-critical applications. Built with ruggedized industrial-grade steel, it contains an integrated high-speed communication backplane that manages robust data exchange between redundant controllers and I/O expansion modules while maintaining system execution during single processor failures or online maintenance.
| Feature | Technical Data |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | FC-CPCHAS-0002 |
| System Compatibility | Honeywell Safety Manager, Experion PKS |
| Safety Integrity Level | Certified up to SIL 3 (IEC 61508) |
| Redundancy Support | Dual Control Processor (CP) module capacity |
| Internal Power Consumption | 5V-1: 0.05 A / 5V-2: 0.05 A |
| Dimensions (H x W x D) | 177 mm x 482.6 mm x 280 mm (7 in x 19 in x 11 in) |
| Rack Units | 4 HE (Standard 19-inch Rack Mount) |
| Net Weight | 5.8 kg (12.8 lbs) |
| Construction | Ruggedized industrial-grade steel with backplane |
| Connector Pin | Function |
|---|---|
| 5V-1 | Internal primary 5 V DC logic power supply connection (0.05 A) |
| 5V-2 | Internal secondary 5 V DC logic power supply connection (0.05 A) |
| CP Slot 1 & 2 | Backplane interconnect slots for redundant Control Processors |
| I/O Bus | High-speed communication interface connecting controller to I/O chassis |
