Modulo di uscita digitale Honeywell Safety Manager FC-SDOL-0424

SKU FC-SDOL-0424

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Honeywell
  • Product No.: FC-SDOL-0424
  • Origin United States
  • Product Type: Moduli di uscita digitale di sicurezza
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Output Modules Safety Manager
Quantità
Call sales Contact

Product Description

Description

To manage safety-critical field actuators within Honeywell Safety Manager environments, the FC-SDOL-0424 serves as a ruggedized fail-safe digital output module. This industrial component features four monitored output channels designed to drive 24 Vdc loads such as solenoid valves, indicators, and interposing relays up to 1 A per channel. Built-in short-circuit protection and overload detection mechanisms ensure high system availability and safety integrity in demanding industrial process control topologies. Each channel is monitored for line monitoring capabilities, allowing the safety controller to track field-side wiring integrity in real time.

Features

  • Four independent, short-circuit proof solid-state source output channels operating at 24 Vdc.
  • High-integrity diagnostic functions including overload detection and off-state leakage monitoring.
  • Internal fail-safe architecture designed for high-availability Safety Instrumented Systems (SIS).
  • Compact physical footprint conforming to standard Eurocard dimensions (4 HP width, 3U height).
  • Integrated watchdog (WDG) input verification to align output states with controller commands.

Applications

  • Emergency Shutdown Systems (ESD) in petrochemical plants.
  • Fire and Gas (F&G) mitigation control and alarming networks.
  • Burner Management Systems (BMS) in industrial boilers and power generation facilities.
  • Critical process safety interlocks in water treatment and chemical refineries.

Technical Specifications

Manufacturer Honeywell
Part Number/Model FC-SDOL-0424
Module Type Digital Output Module (Fail-safe)
Number of Channels 4
Output Configuration 24 Vdc solid-state source (short-circuit proof)
Maximum Channel Current 1 A
Maximum Total Module Load 3.6 A (dissipation limit)
Maximum Load Inductance 0.5 H
Maximum Load Capacitance 1 uF
Overload Detection Threshold Greater than 10 Ohm
Cold Lamp Resistance Greater than 20 Ohm
Voltage Drop Less than 1.3 V at 1 A
Off-state Leakage Current Less than 0.1 mA
Current Sense Voltage Drop Less than 1 V at 1 A
Watchdog (WDG) Input Current 4 mA
Power Requirements (5 Vdc) 15 mA
Power Requirements (24 Vdc Internal) 50 mA
Power Requirements (24 Vdc External) 15 mA (without output load)
Space Requirements 4 TE, 3 HE (4 HP, 3U rack space)
Shipping Weight 2 kg

Installation Guidelines

  • Mounting: Insert the module into an allocated slot within a compatible 3U Safety Manager rack, ensuring secure locking and alignment with backplane connectors.
  • Wiring: Field connection paths must use correctly rated wire gauges to handle continuous 1 A loads. Route low-voltage diagnostic lines separated from high-current AC power cables.
  • Cooling: Maintain clearance margins at the top and bottom of the subrack assembly to allow convective airflow, keeping operating temperatures within specifications.

Compliance and Certifications

  • CE
  • TUV (for safety instrumented functions up to SIL 3)
  • UL Listed
  • CSA Certified
  • FM Approved (Class I, Division 2 Hazardous Locations)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the maximum output current capacity per channel for the FC-SDOL-0424?
Each of the 4 channels supports a maximum continuous current of 1 A, with a maximum module-wide load limit of 3.6 A due to thermal dissipation parameters.
Does the FC-SDOL-0424 digital output module support short-circuit protection?
Yes, the module is equipped with solid-state source outputs that are fully short-circuit proof and include overload detection thresholds.
Which safety systems is the FC-SDOL-0424 compatible with?
The module is designed for Honeywell Safety Manager systems and is certified by TUV for use in safety instrumented systems (SIS) up to SIL 3.
