Description

This Siemens 6AV3535-1FA01-0AX0 is an OP 35 Operator Panel from the Coros HMI series, designed for process monitoring and control in industrial automation systems. The unit features a monochrome LC display with pixel graphics for clear data visualization. It provides extensive connectivity through four integrated interfaces, including TTY/V.24, X.27/TTY, and MPI/PPI. This model is supplied without a direct keypad, offering flexibility for custom mounting and integration into control cabinets or existing operator stations. As an obsolete part, it serves as a direct replacement for maintaining legacy systems.

Features

• Monochrome Liquid Crystal Display (LCD) with pixel graphics.
• Four integrated communication interfaces for versatile connectivity.
• Supports TTY/V.24, X.27/TTY, and MPI/PPI protocols.
• Designed without an integrated keypad for flexible system design.
• Part of the Siemens Coros HMI product family.

Applications

• Machine control and process visualization.
• Legacy system maintenance and spare parts replacement.
• Industrial production lines.
• Data entry and monitoring stations in manufacturing environments.

Technical Specifications

Installation Guidelines

1. 1 De-energize the entire control cabinet and associated machinery. Follow all local Lockout/Tagout (LOTO) procedures to prevent accidental startup.
2. 2 Prepare the panel cutout according to the device's mechanical dimensions. Ensure the mounting surface is clean, flat, and provides adequate support.
3. 3 Secure the operator panel into the cutout using the appropriate mounting hardware. Ensure a proper seal is achieved if the application requires a specific IP rating.
4. 4 Connect the power supply wiring to the designated terminals. Verify the voltage matches the panel's requirements. Connect the functional earth (FE) or protective earth (PE) terminal to the cabinet's ground bus.
5. 5 Connect the communication cables (TTY, MPI/PPI) to the corresponding ports. Route cables away from high-voltage lines to minimize electromagnetic interference. Use shielded cables where specified.
6. 6 After all connections are verified, remove LOTO devices and re-energize the system. Proceed with software configuration and communication testing.
