Description

The 6AV3617-1JC20-0AX2 is a SIMATIC HMI OP17/DP operator panel engineered for reliable machine interaction in industrial automation environments. This device features a clear LC display with LED backlighting, offering flexible configuration options to display either 4 lines of 20 characters or 8 lines of 40 characters. It is specifically designed for integration with SIMATIC S7 and M7 systems, utilizing a PROFIBUS DP interface with communication speeds up to 1.5 Mbaud for efficient data exchange.

Equipped with a tactile keys-based operation interface, this panel is built to withstand continuous industrial operation. The 6AV3617-1JC20-0AX2 includes 256 kbyte of memory for application data and operates on a 24V DC supply. As an obsolete product in the Siemens lifecycle (succeeding the 6AV3617-1JC20-0AX1), it remains a vital component for the maintenance and support of existing legacy production lines.

Features

• Display: LC display, LED backlit
• Resolution/Formatting: 4 lines x 20 characters or 8 lines x 40 characters
• Operation: Tactile key-based input
• Communication: PROFIBUS DP interface (up to 1.5 Mbaud)
• Compatibility: SIMATIC S7 and M7 system integration
• Memory: 256 kbyte
• Power: 24V DC supply voltage
• Certifications: UL and CSA approved

Applications

• Legacy industrial control system monitoring
• Machine interface for SIMATIC S7/M7 PLC architectures
• Production line status visualization
• Retrofitting and maintenance of existing HMI stations

Technical Specifications

Installation Guidelines

• Mounting: Ensure the panel is mounted in an enclosure cutout compliant with the required dimensions to maintain structural integrity.
• Power Supply: Connect to a stable 24V DC power source. Verify polarity before energizing to prevent internal circuitry damage.
• Communication: Ensure PROFIBUS DP cable shielding is properly grounded to mitigate electromagnetic interference (EMI) in high-noise factory environments.
• Environment: Avoid mounting in areas exceeding specified ambient operating temperatures; ensure adequate ventilation behind the panel.
• Maintenance: As this is an obsolete module, keep a backup of the project file configured for this unit, as replacements may be restricted to existing stock.
