Description

This product is a Siemens 6AV7703-2CC10-0AD0, a standard configuration of the SIMATIC PANEL PC 870 series. It is an industrial-grade panel computer designed for human-machine interface (HMI) and control tasks. This unit features a 12.1-inch color TFT display, an Intel Celeron 1.2 GHz processor, and 256 MByte of RAM. It is equipped with a 40 GByte EIDE hard drive, a CD-ROM drive, and comes pre-installed with a multi-language version of Windows 2000. The package includes a mains cable with a European plug for operation on a 230V supply.

Features

• 12.1-inch integrated color TFT display for visualization.
• Powered by an Intel Celeron 1.2 GHz processor.
• Equipped with 256 MByte of system RAM.
• Includes a 40 GByte EIDE hard disk drive for data and application storage.
• Integrated CD-ROM drive for software installation and data access.
• Pre-loaded with Windows 2000 Multi-language operating system (English, German, French, Italian, Spanish).
• Designed for a 230V AC power supply.

Applications

• Machine-level operator control and monitoring.
• Process visualization and data acquisition (SCADA).
• Industrial data logging and reporting.
• Factory floor information systems.
• Control panel integration for manufacturing lines.

Technical Specifications

Installation Guidelines

1. 1 Prepare Mounting Location: Ensure the panel cutout dimensions are correct and the mounting surface is clean, flat, and can support the weight of the unit. Verify adequate clearance for ventilation and cable routing at the rear of the device.
2. 2 Mount the Unit: Insert the Panel PC into the prepared cutout from the front. Secure it from the rear using the provided mounting clamps, tightening them evenly to ensure a proper seal against the panel surface. Do not over-torque the clamps.
3. 3 Connect Protective Earth (PE): Connect a low-impedance protective earth conductor to the designated PE terminal on the chassis. This is a critical safety connection and must be established before any other connections are made.
4. 4 Connect Power and Peripherals: With the main power source confirmed OFF, connect the 230V AC mains cable. Connect any required peripherals such as keyboards, mice, and network cables to their respective ports. Ensure all cables are routed neatly and secured to prevent strain.
5. 5 Power-Up and System Check: After verifying all connections are secure and the work area is clear, restore power to the unit. Observe the boot sequence to ensure the operating system loads correctly. Proceed with application-specific software installation and configuration.
