Siemens 6AV7881-4AE00-6EA0 SIMATIC IPC277D Nanopanel PC

SKU 6AV7881-4AE00-6EA0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7881-4AE00-6EA0
Origin Germany
Product Type: Panel PC
Barcode: 85371098
Payment: T/T, Western Union
Weight: 0.017 kg
Dimensions: 60.0 x 56.5 x 30.0 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6AV7881-4AE00-6EA0 is a SIMATIC IPC277D Nanopanel PC designed for machine-level visualization and control tasks. This unit features a 15-inch TFT touch display and is powered by an Intel Atom E660 processor. It is configured with 2 GB of RAM and a 240 GB SATA Solid-State Drive for reliable, fast-booting performance. Connectivity is provided through dual Gigabit Ethernet ports, multiple high-current USB 2.0 ports, and a serial interface. The system operates on a standard 24 V DC industrial power supply and comes pre-installed with Windows 7 SP1 (MUI).

Features

15-inch TFT resistive touch display
Intel Atom E660 processor operating at 1.3 GHz
2 GB of installed system RAM
240 GB SATA Solid-State Drive (SSD)
Pre-installed Windows 7 SP1 (MUI) operating system
Dual 10/100/1000 Mbps Ethernet RJ45 ports
Front-accessible USB port for convenient access
CompactFlash slot for storage expansion or data transfer

Applications

Human-Machine Interface (HMI) for process control systems
Machine-level data acquisition and logging
Industrial automation and plant floor visualization
Small-scale SCADA and control nodes

Technical Specifications

Category	Specification
General
Manufacturer	Siemens
Product Series	SIMATIC IPC277D
Part Number	6AV7881-4AE00-6EA0
Product Type	Nanopanel PC
Display
Type	TFT with Touchscreen
Size	15 inch
Processing & Memory
CPU	Intel Atom E660
CPU Clock Speed	1.3 GHz
Memory (RAM)	2 GB
Storage
Type	Solid-State Drive (SSD), SATA
Capacity	240 GB
Expansion	CompactFlash Slot
Software
Operating System	Windows 7 SP1, MUI
Bundled Software	Without SIMATIC Software
Interfaces
Ethernet	2x RJ45 (10/100/1000 Mbps)
USB	3x USB 2.0 (High Current), 1x Front USB
Serial	1x COM1
Electrical
Power Supply	24 V DC
Logistics & Compliance
Product Lifecycle Status	Phase-Out
Country of Origin	Germany (Estimate)
Package Dimensions (Calculated)	60.0 x 56.5 x 30.0 cm
Shipping Weight	17.00 kg
Commodity Code	85371098
ECCN	5A992

Installation Guidelines

CRITICAL WARNING: RISK OF ELECTRIC SHOCK

Installation must be performed exclusively by qualified personnel. Disconnect and lock out all power sources before accessing terminals or making connections. Failure to de-energize equipment can result in severe injury or death.

1 Ensure the control cabinet is de-energized and locked out. Verify the absence of voltage before proceeding.
2 Prepare the panel cutout according to the manufacturer's dimensional drawings. Ensure the mounting surface is clean, flat, and provides adequate support.
3 Insert the Panel PC into the cutout from the front. Secure it from the rear using all provided mounting clamps, tightening them evenly to the specified torque to ensure a proper seal.
4 Connect the 24 V DC power supply to the designated terminals. Double-check for correct polarity (+/-) before connecting. Use appropriately sized conductors for the load.
5 Connect the chassis to a dedicated protective earth (PE) or functional ground point using a low-impedance conductor to minimize electrical noise and ensure safety.
6 Connect Ethernet, USB, and serial communication cables as required. Ensure proper cable routing and strain relief to prevent damage to connectors.
7 After verifying all connections, remove the lockout/tagout and re-energize the cabinet. Power on the Panel PC and confirm that the operating system boots correctly.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What operating system is installed on the 6AV7881-4AE00-6EA0?

This unit comes pre-installed with Windows 7 Service Pack 1, Multi-language User Interface (MUI).

What are the main communication interfaces available?

It features two Gigabit Ethernet (10/100/1000 Mbps) ports, three high-current USB 2.0 ports, a front USB port, and one serial COM1 port.

What is the required input power for this Panel PC?

The device requires a 24 V DC power supply.

Does this model include any SIMATIC software?

No, the product description specifies it is supplied 'WITHOUT SIMATIC SOFTWARE'.

What is the storage configuration?

It is equipped with a 240 GB SATA Solid-State Drive (SSD) and includes a CompactFlash slot for additional storage.
