Description

The Siemens 6ES7660-0JD11-2BB0 is a SIMATIC PCS7 Industrial Workstation IPC547C, designed for robust operation in industrial environments. This unit functions as an OS Server, featuring an Intel Core 2 QUAD Q9400 processor (2.66 GHz, 1333 MHz FSB, 6 MB L2 cache, EM64-T, VT). It includes an internal RAID1 storage configuration with two 500 GB SATA hard disk drives, 2.0 GB DDR2 SDRAM (configured as 2 x 1.0 GB), and a DVD+/RW optical drive. The workstation comes with PCS7 V7.1 + SP3 pre-installed, running on Windows Server 2003 Standard, Multi-User Interface (MUI) supporting English, German, French, Italian, Spanish, and Chinese, along with 5 Client Access Licenses (CAL). Connectivity is provided via a DVI-D extension adapter, and the unit is powered by a 110/230 V industrial power supply unit, supplied with a power supply cable for Europe.

Features

• Intel Core 2 QUAD Q9400 Processor (2.66 GHz, 1333 MHz FSB, 6 MB L2 cache, EM64-T, VT)
• 2.0 GB DDR2 SDRAM (2 x 1.0 GB)
• RAID1 Storage with 2 x 500 GB SATA HDDs
• DVD+/RW Optical Drive
• Pre-installed PCS7 V7.1 + SP3 Software
• Windows Server 2003 Standard Operating System (MUI with 5 CAL)
• DVI-D Extension Adapter
• 110/230 V Industrial Power Supply Unit

Applications

• Industrial control systems utilizing SIMATIC PCS7
• Operating system server roles in automation networks
• Data processing and storage in demanding industrial environments
• Human Machine Interface (HMI) and supervisory control applications

Technical Specifications

Installation Guidelines

1. Power De-energization: Ensure all power to the installation area is disconnected and locked out before commencing any work.
2. Mounting: Install the workstation securely within a standard industrial rack, ensuring adequate ventilation space around the unit.
3. Power Connection: Connect the provided power supply cable to the 110/230 V industrial power supply unit. Verify the correct voltage supply is available at the installation site.
4. Grounding: Establish a proper earth ground connection for the workstation chassis to ensure electrical safety and minimize interference.
5. Peripheral Connections: Connect necessary peripherals such as monitors (via DVI-D), keyboards, and mice.
6. Network Integration: Connect the workstation to the industrial network as required by the PCS7 system architecture.
7. Cable Management: Route all power, signal, and network cables neatly and securely, away from potential sources of electrical noise or physical damage.
8. System Power-Up: After all connections are verified, restore power to the system and monitor for proper boot-up and operation.
