Description

The 6GK5216-4BS00-2AC2 is a SCALANCE XC216-4C Managed Layer 2 IE Switch engineered for robust industrial network communication. This high-performance device is IEC 62443-4-2 certified, ensuring stringent cybersecurity standards are met for industrial automation environments. It features a versatile port configuration including 12 x 10/100 Mbps RJ45 ports and 4 x 1000 Mbps combo ports that support either SFP modules or standard RJ45 copper connections.

This managed switch offers advanced redundancy functions and office-grade networking features such as RSTP (Rapid Spanning Tree Protocol) and VLAN support, making it suitable for complex network architectures. Designed for harsh environments, it operates effectively within a temperature range of -40 degC to +70 degC. The unit includes a dedicated console port for management, diagnostic LEDs for status monitoring, and supports both PROFINET IO and Ethernet/IP protocols. Installation options include DIN rail, S7 mounting rail, or wall mounting, and it features a dedicated slot for a C-PLUG for easy configuration backup and replacement.

Features

• IEC 62443-4-2 certified for enhanced industrial security
• 12 x 10/100 Mbps RJ45 ports
• 4 x 1000 Mbps combo ports (SFP or RJ45)
• Managed Layer 2 functionality with RSTP and VLAN support
• Supports PROFINET IO and Ethernet/IP
• Redundant power supply input for high availability
• Wide operating temperature: -40 degC to +70 degC
• Includes C-PLUG slot for configuration storage

Applications

• Automated industrial manufacturing networks
• Critical infrastructure and process automation
• PROFINET and Ethernet/IP-based control systems
• Building automation and facility networking
• Applications requiring high-security IEC 62443 compliance

Technical Specifications

Installation Guidelines

• Mounting: The switch can be mounted on a 35 mm DIN rail, S7 mounting rail, or directly to a wall surface using the integrated mounting brackets.
• Power Connection: Connect the redundant power supply to the provided terminals to ensure network uptime in the event of a single power source failure.
• Grounding: Ensure the device is properly connected to the system functional earth to maintain electromagnetic compatibility and safety.
• Configuration: Use the console port or web-based management interface for initial setup; use the C-PLUG memory module to save or transfer device configurations for streamlined maintenance.
• Ventilation: Allow for sufficient clearance above and below the device to ensure optimal convective cooling in high-temperature environments.
