Allen-Bradley 80190-380-02-R Signal Conditioning Board

SKU 80190-380-02-R

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Allen-Bradley
Product No.: 80190-380-02-R
Country of origin:United States
Product Type: Signal Conditioning Board
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 320g
Dimensions: 25.1cm x 19cm x 2.6cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 80190-380-02-R is a signal conditioning circuit board assembly designed specifically for industrial inverter and variable frequency drive (VFD) systems. The 80190-380-02-R operates as a critical intermediary interface that processes, scales, and linearizes feedback and control signals from the field before they reach the main controller logix core. By supporting standard industrial analog signal formats and providing galvanic channel isolation, this assembly effectively eliminates ground loops and dampens high-frequency electromagnetic interference (EMI) typical in high-power electronics environments.

Features

Equipped with 8 isolated input channels to maximize electrical protection and suppress field-side signal noise
Features 4 isolated output channels for precise routing and allocation of conditioned control loops
Universal integration flexibility with direct support for standard 0-10V voltage and 4-20mA current loops

Applications

Inverter control loop signal conditioning and feedback isolation
Interface adaptation for industrial variable frequency drives (VFDs)
Multi-channel analog data acquisition in electrical power sub-assemblies

Technical Specifications

Parameter	Specification
Manufacturer	Allen-Bradley
Product Model	80190-380-02-R
Spare Model	8019038002R
Product Type	Signal Conditioning Board (Circuit Board Assembly)
Tariff Code	8537101190
Country of Origin	USA
Power Supply	24V DC (+/-10%)
Current Draw	85mA typical
Input Channels	8 isolated
Output Channels	4 isolated
Signal Types Supported	0-10V, 4-20mA
Operating Temperature	-20 degC to +60 degC
Storage Temperature	-40 degC to +85 degC
Humidity	5-95% (non-condensing)

Installation Guidelines

Power Quality: Connect a stable 24V DC (+/-10%) external power supply. Avoid sudden voltage surges to preserve the measurement linearity and calibration of the operational amplifiers.
Isolation Wiring: Utilize the independent channels correctly; do not tie the reference grounds of isolated fields together, as it defeats the board's built-in galvanic isolation barrier.
Environmental Layout: Mount the board inside an appropriately rated enclosure to maintain operations within the specified -20 degC to +60 degC temperature window and prevent condensation.

FAQ

What standard signal types are supported by this device?

The device natively supports standard industrial analog signals including 0-10V voltage loops and 4-20mA current loops.

What are the exact power supply requirements for the module?

The module requires a stable 24V DC power supply with a tolerance of +/-10%, and it features a typical current draw of 85mA.

How many isolated channels does the board provide?

The board features a total of 8 electrically isolated input channels and 4 electrically isolated output channels.
