Option 00 (0 mm unthreaded length), Option 05 (50 mm case length), and Option 05 (0.5 m total length) specify this 3300 XL 8 mm proximity probe configuration — 330103-00-05-05-01-05, which features an unarmored standard metric case and a coaxial ClickLoc connector with a pre-installed connector protector.
In contrast to variants with longer cable runs (such as 1.0 m or 2.0 m options) or armored protection sleeves, this 330103 configuration provides a compact 0.5-meter standard cable solution. The integrated connector protector guards the ClickLoc terminal from mechanical damage and moisture intrusion, making it suitable for confined spaces inside machine housings. With a fully threaded 50 mm case and zero unthreaded length, the probe offers maximum mounting adjustability within standard metric brackets.
Industrial machinery vibration monitoring and axial position measurements in rotating equipment. Commonly used on steam turbines, gas turbines, centrifugal compressors, pumps, and generators to track shaft displacement, differential expansion, and keyphasor reference signals.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-05-05-01-05 | 3300 XL 8 mm proximity probe, M10 x 1 thread, without armor |
| A - Unthreaded Length Option | 00 | 0 mm |
| B - Overall Case Length Option | 05 | 50 mm |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) |
| D - Connector and Cable-Type Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| E - Agency Approval Option | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Value |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-00-05-05-01-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 |
| Armor Option | None |
| Unthreaded Length | 0 mm |
| Case Length | 50 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature male coaxial ClickLoc |
| Connector Protector | Included (Option 01) |
| Cable Type | Standard 75 ohm coaxial cable |
| Probe Tip Diameter | 8.0 mm (0.31 inches) |
| Operating Temperature (Probe) | -52 degC to +177 degC (-62 degF to +350 degF) |
| Differential Pressure Seal | Seals up to 7.0 bar (100 psi) |
| Minimum Target Diameter | 15.2 mm (0.6 inches) |
| Linear Range | 2.0 mm (80 mils) nominal |
| Weight | 0.16 kg |
| Dimensions | 130 mm x 130 mm x 40 mm (H x W x D) |
| Interface Component | Specifications |
|---|---|
| Connector Type | Miniature male coaxial ClickLoc with gold-plated contact pins |
| Coaxial Cable | 75 Ohm low-loss shielded cable |
Mount the probe in M10 x 1 threaded holes using a standard metric bracket. Verify that the thread engagement does not exceed the limit of 15 mm to prevent binding. Verify that the probe tip has clear space from surrounding metal (at least 1.5 times the probe tip diameter) to prevent side-loading or cross-talk. Install the connector protector properly to seal the coaxial junction from fluid ingress and contamination. Maintain a minimum bend radius of 25.4 mm (1.0 inch) for the probe coaxial cable.
CSA, ATEX, IECEx approvals for use in hazardous areas (Intrinsically Safe and Non-Incendive configurations).
