330103-00-09-10-02-CN: 3300 XL 8 mm proximity probe, M10 x 1 metric thread, without armor. This specific configuration features Option 00 (0 mm unthreaded length), Option 09 (90 mm case length), Option 10 (1.0 meter total length), Option 02 (miniature ClickLoc coaxial connector, standard cable), and Suffix -CN (China hazardous area approval package containing NEPSI and CCC certifications).
This unarmored metric probe measures shaft dynamic vibration, axial position, and speed on critical rotating machinery. The 90 mm fully-threaded case enables mounting depth tuning within deep M10 x 1 ports. Suffix -CN certifies the assembly for safe operation in explosive atmospheres in China under CCC and NEPSI regulations, replacing the standard -05 global agency approval.
This 90 mm metric probe is designed for machinery protection systems where deep-threaded mounting wells or thick machine casings require extended thread reach. It is commonly applied in:
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-09-10-02-CN | 3300 XL 8 mm probe, M10 x 1 thread, without armor |
| A - Unthreaded Length Option | 00 | 0 mm unthreaded length |
| B - Overall Case Length Option | 09 | 90 mm case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Suffix - CN | -CN | China hazardous area approval package (NEPSI and CCC) |
| Manufacturer | Bently Nevada |
| Model / Part Number | 330103-00-09-10-02-CN |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Thread Size | M10 x 1 thread (without armor) |
| Unthreaded Length | 0 mm |
| Case Length | 90 mm |
| Total Length | 1.0 meter (3.3 feet) |
| Cable Type | Standard coaxial, 75 ohm, 3.68 mm outside diameter |
| Connector Type | Miniature gold-plated ClickLoc male coaxial connector |
| Nominal DC Resistance | 7.59 ohms (nominal center conductor to outer conductor) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Pressure Rating | Up to 7.0 bar (100 psi) differential pressure |
| Weight | 100 g (0.10 kg) |
| Dimensions | 100 mm x 100 mm x 30 mm (H x W x D) (coiled package size) |
Proper installation ensures accurate transducer system performance:
The -CN suffix configures this probe with specific certifications for the Chinese market:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-09-10-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 100g
Dimensions: 100 mm x 100 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
