Bently Nevada 330780-91-CN 3300 XL 11 mm Proximitor Sensor

SKU 330780-91-CN

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330780-91-CN
Country of origin:United States
Product Type: 3300 XL 11 mm Proximitor Sensor
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

330780-91-CN specifies the 9.0 m DIN-rail mount configuration of the 3300 XL 11 mm Proximitor Sensor, equipped with the China hazardous area approval package. This sensor performs non-contacting eddy-current displacement measurement within 3300 XL 11 mm monitoring chains, outputting an analog voltage directly proportional to the distance between the probe tip and the observed target surface.

This variant pairs with 3300 XL 11 mm probes and extension cables to monitor shaft vibration, axial position, and rotor dynamics. Unlike the 5.0 m options or panel-mount configurations, this model is factory-calibrated for a 9.0 m system length and integrates DIN-rail mounting hardware. Additionally, the -CN suffix designates NEPSI and CCC certifications required for localized hazardous area compliance in the Chinese market.

Features

Option 91 specifies a 9.0-meter system length configured for DIN-rail mounting.
Suffix -CN designates the China hazardous area approval package including NEPSI and CCC certification.
Accepts input from 3300 XL 11 mm proximity probes and matching extension cables.
Generates a continuous analog voltage output of 3.94 V/mm (100 mV/mil).
Uses gold-plated brass ClickLoc coaxial connectors for physically secure cabling.
Constructed with an A380 aluminum housing.

Applications

Steam and gas turbine shaft vibration and axial position monitoring
Centrifugal and axial compressor rotor dynamics
Industrial pump and generator shaft position tracking
Critical rotating machinery protection systems

Ordering Information

Option / Segment	Code on This SKU	Meaning from Datasheet
Orderable Part Number	330780-91-CN	3300 XL 11 mm Proximitor Sensor with 9.0 m system length, DIN-rail mounting, and China approvals
A: Total Length and Mounting Option	91	9.0 meters (29.5 feet) system length, DIN-rail mount
Suffix	-CN	China hazardous area approval package (NEPSI + CCC + applicable markings)

Technical Specifications

Manufacturer	Bently Nevada
Part Number / SKU	330780-91-CN
System Type	3300 XL 11 mm Proximity Transducer System
Sensor Input Compatibility	Accepts one 3300 XL 11 mm proximity probe and extension cable
Power Input Requirements	-17.5 Vdc to -26 Vdc (without barriers) at 12 mA maximum consumption; -23 Vdc to -26 Vdc (with barriers)
Analog Output Resistance	50 ohms
Incremental Scale Factor (ISF)	3.94 V/mm (100 mV/mil) +/- 10% typical
Linear Range	4.0 mm (160 mils), beginning at approximately 0.5 mm (20 mils) from target
Recommended Gap Setting	2.5 mm (100 mils)
Frequency Response	0 to 8 kHz (+0, -3 dB typical)
Housing Material	A380 aluminum
Connector Material	Gold-plated brass ClickLoc
Operating Temperature	-52 degC to +100 degC
Relative Humidity Limit	100% condensing (non-submersible with protected connectors)

Connections and Interfaces

Terminal Label	Terminal Connection Function
VT	Voltage Transmitter / Power Supply (-24 Vdc nominal input)
COM	Common Ground Reference
OUT	Transducer Analog Output Signal

Installation Guidelines

Ensure that the Proximitor sensor is mounted on a 35 mm DIN rail in a dry, clean industrial enclosure providing a minimum of IP54 protection. Maintain appropriate clearance for field wiring and terminal connections. Use three-conductor shielded triad cable (0.2 to 1.5 mm2 or 16 to 24 AWG) for connections between the Proximitor sensor and the monitoring system. Verify that the sum of the probe length and extension cable length matches the 9.0 m system calibration length of the sensor.

Compliance and Certifications

The 330780-91-CN transmitter meets the following compliance requirements:

NEPSI (National Supervision and Inspection Centre for Explosion Protection and Safety of Instrumentation) - CN Option
CCC (China Compulsory Certification) - CN Option
CE Mark (EMC Directive 2014/30/EU and RoHS Directive 2011/65/EU)
SIL 2 (HFT = 0) and SIL 3 (HFT = 1) functional safety compliance

FAQ

What does the -CN suffix represent on this Proximitor sensor?

The -CN suffix represents the China hazardous area approval package, certifying compliance under NEPSI and CCC requirements.

What mounting type does option 91 provide for this Proximitor?

Option 91 specifies a 9.0-meter system length configured with DIN-rail mounting hardware.

What probe and extension cable lengths are compatible with this model?

This 9.0 m Proximitor sensor requires a combined probe and extension cable length totaling exactly 9.0 meters to maintain correct calibration.

What is the operating temperature range of this sensor?

The sensor operates within an ambient temperature range of -52 degC to +100 degC (-62 degF to +212 degF).

View all FAQs →

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.
