Bently Nevada

Bently Nevada 330104-15-25-10-02-00 3300 XL 8 mm Proximity Probe

SKU 330104-15-25-10-02-00

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330104-15-25-10-02-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.2 kg
  • Dimensions: 250 mm x 120 mm x 30 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330104-15-25-10-02-00 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantity
Call sales Contact

Product Description

Description

A 150 mm unthreaded length (Option 15) and a 250 mm overall case length (Option 25) specify this M10 x 1 metric threaded, armored configuration—Bently Nevada 330104-15-25-10-02-00 3300 XL 8 mm proximity probe.

Unlike unarmored alternatives in the same product line, this variant incorporates flexible stainless steel armor over its 1.0-meter coaxial cable (Option 10) to guard the signal path against physical wear, abrasion, and aggressive industrial debris. The probe terminates in a miniature coaxial ClickLoc connector (Option 02) and is configured for commercial environments where specialized hazardous area agency approvals are not required (Option 00). Operating on eddy-current principles, this probe measures static displacement and dynamic shaft vibration when integrated with a matching 3300 XL Proximitor sensor and standard extension cable.

Features

  • Option 15 defines a 150 mm unthreaded section on the metric M10 x 1 threaded body.
  • Option 25 specifies a 250 mm overall case length built from corrosion-resistant stainless steel.
  • Option 10 delivers a 1.0-meter (3.3 feet) total cable length covered by flexible stainless steel armor and an FEP outer jacket.
  • Option 02 provides a gold-plated miniature ClickLoc coaxial connection for robust electrical continuity.
  • Option 00 is configured for non-hazardous locations and standard industrial monitoring loops.
  • Polyphenylene sulfide (PPS) tip is chemically sealed to prevent process fluid leaks through the probe head.

Applications

  • Shaft radial vibration and axial thrust position measurements on fluid-film bearing machinery.
  • Machinery protection monitoring on heavy-industrial steam turbines, gas turbines, and generators.
  • Critical rotating equipment deployments such as high-pressure pumps, compressors, and industrial gearboxes.

Ordering Information

This table decodes the orderable configuration segments for this specific probe:

Segment / Option Group Code Meaning / Specification
Orderable Part Number 330104-15-25-10-02-00 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor
Option A - Unthreaded Length 15 150 mm unthreaded length (increments of 10 mm)
Option B - Overall Case Length 25 250 mm overall case length (increments of 10 mm)
Option C - Total Length 10 1.0 meter (3.3 feet) total cable length
Option D - Connector / Cable Type 02 Miniature ClickLoc coaxial connector, standard cable with flexible stainless steel armor
Option E - Agency Approval 00 No agency approvals required

Technical Specifications

Manufacturer Bently Nevada
Part Number / Model 330104-15-25-10-02-00
Transducer System 3300 XL 8 mm Proximity Transducer System
Thread Size M10 x 1 metric thread
Armored Cable Flexible AISI 302 or 304 SST with FEP outer jacket
Unthreaded Length 150 mm
Overall Case Length 250 mm
Total Length 1.0 meter (3.3 feet)
Connector Type Miniature coaxial ClickLoc
Probe Tip Material Polyphenylene sulfide (PPS)
Probe Case Material AISI 303 or 304 stainless steel (SST)
Operating and Storage Temperature -52 degC to +177 degC (-62 degF to +350 degF)
Probe Tip Pressure Rating Differential pressure seal with Viton O-ring
Linear Range 2.0 mm (80 mils), starting at approximately 0.25 mm (10 mils) from target
Dimensions 250 mm x 120 mm x 30 mm (H x W x D)
Weight 0.20 kg

Installation Guidelines

  • Do not bend the armored cable below a minimum bend radius of 25.4 mm (1.0 in) to preserve mechanical integrity.
  • Ensure the probe tip has a minimum clearance of 15 mm from any surrounding conductive metals to prevent eddy-current field distortion.
  • Maintain thread engagement limits within 15 mm for the M10 x 1 threads to avoid physical binding.
  • Limit the installation torque on the probe case to a maximum recommended 22.6 N-m (200 in-lbf). Restrict the first three threads to 7.5 N-m (66 in-lbf) of torque.
  • Isolate and seal the coaxial connection from moisture and environmental contaminants using a junction box or protective silicone self-fusing tape.

Compliance and Certifications

This standard commercial configuration complies with the following industrial standards:

  • CE Compliant
  • RoHS Compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What configuration does the Bently Nevada 330104-15-25-10-02-00 specify?
This model represents a 3300 XL 8 mm proximity probe with an M10 x 1 metric thread, integrated flexible stainless steel armor, a 150 mm unthreaded length, a 250 mm overall case length, a 1.0-meter total cable length, a miniature ClickLoc coaxial connector, and no agency approvals.
What are the benefits of the flexible armor on the 330104 probe cable?
The flexible AISI 302 or 304 stainless steel armor with its FEP outer jacket shields the delicate internal coaxial cable from physical damage, extreme abrasion, and harsh oil or chemical exposure in heavy industrial machinery environments.
Is this 1.0-meter probe connected directly to the Proximitor sensor?
No, a 1.0-meter probe requires a complementary 3300 XL extension cable (typically 4.0 meters or 8.0 meters) to match the total system length requirement of the 3300 XL Proximitor sensor (either 5.0 meters or 9.0 meters).
What is the recommended installation torque for this metric threaded probe?
The maximum rated torque for the M10 x 1 threaded case is 22.6 N-m (200 in-lbf). Bently Nevada recommends limiting torque to 7.5 N-m (66 in-lbf) during initial thread seating to avoid mechanical binding.
