Option 28 (3300 XL 8 mm probe with multiple approvals) and Option 150 (150 mm probe penetration sleeve) specify this unique PROXPAC XL configuration — 330881-28-04-150-06-02. This integrated transducer assembly features a 40 mm standoff adapter and NPT fittings with a stainless steel reducer to deliver a self-contained monitoring system that eliminates external extension cables. By mounting the 3300 XL Proximitor sensor directly in the housing cover, field wiring connects straight from the machinery monitors to the PROXPAC XL assembly, streamlining overall physical complexity.
Unlike basic options lacking mechanical standoff, this metric variant uses a 3/4-14 NPT mounting thread (Option 02) which is mechanically required to support the integrated 40 mm standoff adapter (Option 04). The body is molded from advanced, glass-reinforced polyphenylene sulfide (PPS) thermoplastic containing conductive fibers to strengthen the outer assembly and protect the interior against hostile chemical and electrostatic environments.
| Option Segment | Code on This SKU | Description / Selected Option |
|---|---|---|
| Orderable Part Number | 330881-28-04-150-06-02 | PROXPAC XL Proximity Transducer, Metric |
| A - Probe and Approvals Option | 28 | 3300 XL 8 mm probe with Multiple Approvals |
| B - Standoff Adapter Option (B Dimension) | 04 | 40 mm standoff adapter length |
| C - Probe Penetration Option (C Dimension) | 150 | 150 mm probe penetration length |
| D - Fittings Option | 06 | One 3/4-14 NPT fitting, one 3/4-14 NPT to 1-1/2-14 NPT SST reducer, and two plugs |
| E - Mounting Thread Option | 02 | 3/4-14 NPT thread (required if ordering Standoff Adapter) |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model Number | 330881-28-04-150-06-02 |
| Product Type | PROXPAC XL Proximity Transducer (Metric) |
| Proximitor Sensor Input | 3300 XL 8 mm proximity probe with 1-metre cable length |
| Power Requirements | Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum; -23 Vdc to -26 Vdc with barriers |
| Supply Sensitivity | Less than 2 mV change in output voltage per volt change in input voltage |
| Output Resistance | 50 Ohm |
| Field Wiring Compatibility | 0.2 to 1.5 mm2 (16 to 24 AWG), 3-conductor shielded triax recommended |
| Linear Range | 2 mm (80 mils), starting approximately 0.25 mm (10 mils) from target |
| Recommended Gap Setting | 1.27 mm (50 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) +/-5% standard |
| System Deviation (DSL) | Less than +/-0.025 mm (+/-1 mil) |
| Housing Material | Ultraviolet (UV) resistant, glass-reinforced polyphenylene sulfide (PPS) thermoplastic containing conductive fibers |
| Sleeve Material and Retaining Chain | AISI 304 stainless steel |
| Outer Sleeve and Retaining Screws | AISI 303 stainless steel |
| Sleeve O-Ring Material | Neoprene |
| Grounding Liner Material | AISI 304 stainless steel |
| Vibration Isolation Material | Extra Soft Cellular Silicone |
| Lid Label Material | Gloss Radiant White Polyester |
| Operating Temperature (Probe Housing and Proximitor) | -52 degC to +100 degC (-62 degF to +212 degF) |
| Storage Temperature | -52 degC to +105 degC (-62 degF to +221 degF) |
| Probe Temperature Range | -52 degC to +177 degC (-62 degF to +351 degF) |
| Environmental Sealing | Type 4X, IP66 (verified by BASEEFA) |
| Relative Humidity | 100% condensing, non-submersible when connectors protected |
| Interface Element | Details / Support |
|---|---|
| Field Wiring Terminals | Direct connection inside housing cover; supports up to 1.5 mm2 (16 AWG) field wire |
| Maximum Field Wiring Distance | 305 metres (1,000 feet) between transducer and monitor |
| Integrated Cable Connections | Pre-routed internal connection eliminating standard external ClickLoc extension cables |
Ensure the housing is securely mounted. The 3/4-14 NPT mounting thread (Option 02) must be fully engaged to ensure the structural integrity of the standoff adapter. Observe the manufacturer-recommended torque limits: apply 29.5 N-m (260 in-lb) to the retaining nut, and 39.3 N-m (350 in-lb) to the probe sleeve locknut. Ensure that sealing washers, plugs, and fittings are correctly installed to prevent moisture from traveling through conduits into the housing interior.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330881-28-04-150-06-02
Country of origin:United States
Product Type: PROXPAC XL Proximity Transducer
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 250g
Dimensions: 60 mm x 110 mm x 110 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
