Designed specifically for energy-saving pump and fan applications, the FR-F840-00310-2-60 variable frequency drive represents Mitsubishi Electric's high-efficiency solution for industrial motor control. This unit features advanced optimum excitation control, which continuously adjusts the motor drive current to deliver maximum efficiency and reduce power consumption under varying load profiles.
Operating within the FR-F800 Series, the FR-F840-00310-2-60 energy-saving inverter is engineered with a dual-rating architecture, supporting both Super Light Duty (SLD) and Light Duty (LD) specifications. This flexibility allows engineers to optimize the drive sizing according to specific torque and overload demands in HVAC, municipal water supply, and general mechanical applications.
| Manufacturer | Mitsubishi Electric |
| Model/Part Number | FR-F840-00310-2-60 |
| Series | FR-F800 |
| Product Type | Energy-Saving Inverter / VFD |
| Applicable Motor Capacity (SLD) | 15 kW |
| Output Overload Current Rating (SLD) | 110% for 60 seconds, 120% for 3 seconds (inverse-time characteristics) at surrounding air temperature 40 degC |
| Output Overload Current Rating (LD) | 120% for 60 seconds, 150% for 3 seconds (inverse-time characteristics) at surrounding air temperature 50 degC |
| Rated Input Voltage | Three-phase 380 to 500 VAC |
| Power Supply Frequency | 50 Hz / 60 Hz |
| Permissible AC Voltage Fluctuation | 323 to 550 VAC, 50 Hz / 60 Hz |
| Dimensions (W x H x D) | 22 cm x 30 cm x 19 cm |
| Weight | 8.3 kg |
To ensure optimal heat dissipation and reliable operation, mount the inverter vertically on a flat, non-flammable surface. Maintain a minimum clearance of 5 cm above and below the unit, and 1 cm on either side to facilitate natural convection. All power and control wiring must be properly shielded and routed separately to minimize electromagnetic interference. Ensure a solid, low-impedance ground connection is established prior to applying main line power.
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: FR-F840-00310-2-60
Country of origin:United States
Product Type: Inverters
Payment: T/T, Western Union
Weight: 8300g
Dimensions: 22 cm x 30 cm x 19 cm
Shipping port: Xiamen
Warranty: 12 months
Designed specifically for energy-saving pump and fan applications, the FR-F840-00310-2-60 variable frequency drive represents Mitsubishi Electric's high-efficiency solution for industrial motor control. This unit features advanced optimum excitation control, which continuously adjusts the motor drive current to deliver maximum efficiency and reduce power consumption under varying load profiles.
Operating within the FR-F800 Series, the FR-F840-00310-2-60 energy-saving inverter is engineered with a dual-rating architecture, supporting both Super Light Duty (SLD) and Light Duty (LD) specifications. This flexibility allows engineers to optimize the drive sizing according to specific torque and overload demands in HVAC, municipal water supply, and general mechanical applications.
| Manufacturer | Mitsubishi Electric |
| Model/Part Number | FR-F840-00310-2-60 |
| Series | FR-F800 |
| Product Type | Energy-Saving Inverter / VFD |
| Applicable Motor Capacity (SLD) | 15 kW |
| Output Overload Current Rating (SLD) | 110% for 60 seconds, 120% for 3 seconds (inverse-time characteristics) at surrounding air temperature 40 degC |
| Output Overload Current Rating (LD) | 120% for 60 seconds, 150% for 3 seconds (inverse-time characteristics) at surrounding air temperature 50 degC |
| Rated Input Voltage | Three-phase 380 to 500 VAC |
| Power Supply Frequency | 50 Hz / 60 Hz |
| Permissible AC Voltage Fluctuation | 323 to 550 VAC, 50 Hz / 60 Hz |
| Dimensions (W x H x D) | 22 cm x 30 cm x 19 cm |
| Weight | 8.3 kg |
To ensure optimal heat dissipation and reliable operation, mount the inverter vertically on a flat, non-flammable surface. Maintain a minimum clearance of 5 cm above and below the unit, and 1 cm on either side to facilitate natural convection. All power and control wiring must be properly shielded and routed separately to minimize electromagnetic interference. Ensure a solid, low-impedance ground connection is established prior to applying main line power.
