C9900-M753 | BECKHOFF | Panneau de commande multi-touch avec CP-Link 4

Description

Facilitating flexible physical integration on the factory floor, the Beckhoff C9900-M753 provides a robust mechanical interface for CP3912 through CP3924 multi-touch Control Panels equipped with push-button extensions. Designed to bridge the gap between human-machine interfaces (HMIs) and support systems, this rotatable and tiltable adapter ensures optimal operator ergonomics and viewing angles. It is engineered specifically for Rittal and Rolec mounting arm systems configured with a 48 mm diameter tube entering from the bottom, offering a secure, vibration-resistant mount for heavy-duty industrial control environments.

Key Features

• Multi-Axis Adjustment: Enables both precise rotation and tilting movements to adapt the panel position to dynamic operating heights and preferences.
• System Compatibility: Explicitly engineered for integration with Beckhoff CP3912, CP3915, CP3916, CP3918, CP3919, CP3921, and CP3924 multi-touch Control Panels.
• Extension Support: Designed to accommodate setups featuring the C9900-Gxxx push-button extension housing.
• Standardized Arm Fitting: Integrates directly with standard 48 mm diameter tube connections from bottom-entry Rittal and Rolec mounting arm systems.

Industrial Applications

• Automotive Assembly Lines: Ergonomic mounting of CP39xx operator terminals at manual assembly and inspection stations.
• Machine Tool Control: Direct integration with heavy CNC machinery frames via swing-arm assemblies.
• Process Plant Visualization: Hygienic and secure positioning of monitoring screens in packaging and chemical processing plants.

Technical Specifications

Empirical Engineering Insights

Alternative Models & Compatibility

The C9900-M753 is specifically designed for configurations utilizing the auxiliary push-button extensions (C9900-Gxxx). If your installation uses a standard CP39xx Control Panel without an additional push-button box, a different adapter variant (such as the standard mounting arm joint without extension clearances) may be required to maintain physical alignment and NEMA/IP seal ratings.

Application Pitfalls & Engineering Notes

When utilizing CP-Link 4 technology over long distances, high physical vibration on poorly supported mounting arms can lead to micro-interruptions in the structural grounding path. Ensure the 48 mm steel mounting tube is bonded securely to the main machine ground, and use the integrated mechanical rotation stops on the adapter to prevent over-rotation, which can shear or fatigue internal CP-Link 4 cables over time.

Commissioning & Wiring Tips

Always route the CP-Link 4 cable (combining power and signal) through the adapter's pivot point with a generous, pre-calculated service loop. Forcing a tight bend radius inside the 48 mm tube entry point will degrade signal integrity and cause intermittent display sync drops or communication timeouts during high-tilt operations.

Installation Guidelines
