BECKHOFF EPP2008-0002 Boîtier EtherCAT P

The EPP2008-0002 is a robust 8-channel digital output EtherCAT P Box from BECKHOFF, specifically designed for distributed control applications where space and wiring efficiency are critical. By integrating the EtherCAT communication protocol with 24 V DC power delivery in a single P-coded M8 connection, this module significantly reduces cabling overhead. Housed in an IP65/66/67-rated enclosure, it provides high-performance output switching for industrial actuators, lamps, and inductive loads in harsh, field-level environments.

Features

• 8 digital output channels for 24 V DC load switching
• EtherCAT P bus interface via 2 x P-coded M8 sockets
• Individually short-circuit proof outputs (0.5 A per channel)
• Suitable for ohmic, inductive, and lamp loads
• Fast switching times (typ. 50 µs TON / 100 µs TOFF)
• Rugged IP65/66/67 protection for direct machine mounting
• Compact, lightweight design (approx. 165 g)

Applications

• Distributed actuator control in automotive or assembly lines
• Harsh-environment signaling and lighting control
• Modular machine automation requiring single-cable power and data
• Robotic cells and end-of-arm tooling control

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Mount the device securely using the integrated mounting points on a stable, vibration-resistant surface.
• Use P-coded M8 connectors for EtherCAT P to ensure reliable power and data transmission.
• Ensure that all unused ports are properly capped and active M12 connectors are tightened to maintain the IP65/66/67 rating.
• Keep the total load current within the design limits to ensure the short-circuit protection features operate effectively.
• Observe ambient temperature limits (-25 to +60 degC) to prevent thermal degradation during continuous high-load operation.

Compliance and Certifications

• CE
• UL
