CS1G-CPU42-V1 | Omron | Unité CPU

Description

Engineered for medium-to-large-scale machine control and industrial automation, the Omron CS1G-CPU42-V1 serves as a high-performance central processing unit within the modular CS1-series programmable logic controller (PLC) architecture. This CPU Unit optimizes processing speeds and instruction execution times to handle demanding automation tasks across complex production environments.

The CS1G-CPU42-V1 features a program capacity of 10K steps and a robust memory capacity of 64K words, facilitating advanced sequential and process control configurations. Designed for seamless integration, it supports up to 960 local I/O points, allowing for highly flexible system expansion. Its design ensures compatibility with existing CS1 rack systems, communication modules, and digital/analog I/O cards, providing a scalable path for upgrading legacy systems without full rewiring.

Features

• Reliable execution of ladder logic, structured text, and SFC programming.
• Compatible with a wide range of Omron CS1-series communication, motion control, and special I/O modules.
• Battery-backed RAM to preserve critical system variables, program data, and event logs during power loss.
• Built-in peripheral and RS-232C ports for easy programming tool connection, HMI interfacing, and serial communications.
• Supports extensive diagnostic self-tests, including memory checks, program errors, and CPU run-time monitoring.

Applications

• Automated manufacturing assembly lines
• Water and wastewater treatment processing
• Material handling and conveyor systems
• Packaging machinery and automated bottling plants
• HVAC and building automation environmental control

Technical Specifications

Installation Guidelines

For reliable system performance and thermal management, install the CS1G-CPU42-V1 CPU Unit on a compatible CS1D or CS1W backplane in the dedicated CPU slot. Ensure the backplane is mounted vertically inside an enclosure with a minimum clearance of 50 mm above and below the rack to allow proper airflow. Keep the unit away from high-voltage cables and heavy electrical machinery to minimize electromagnetic interference (EMI). Verify that the system is completely powered down before inserting or removing the CPU unit to prevent damage to the backplane connectors.

Compliance and Certifications

• CE compliant (low voltage and EMC directives)
• UL Listed (Class I, Division 2 for hazardous locations)
• cULus certified
