R7D-AP08H | Omron | Variateur servo SmartStep

Description

Engineered for precise speed and torque control in automated systems, the Omron R7D-AP08H is a high-performance AC servo drive operating within the SmartStep series ecosystem. This drive bridges the gap between stepper systems and fully closed-loop AC servo technologies, offering simple configuration alongside high-speed dynamic response. Designed to power AC servo motors up to 750 W, the unit operates on a 200 VAC input class, making it ideal for integration into standard industrial control panels.

The R7D-AP08H utilizes advanced processing algorithms to minimize tracking errors and optimize motor performance under varying load profiles. Its robust power stage accommodates substantial momentary overcurrent requirements, ensuring reliable operation during rapid acceleration and deceleration cycles without sacrificing system longevity.

Features

• Closed-loop AC servo performance with the operational simplicity of a stepper system.
• Direct integration with 200 VAC power distribution networks.
• High peak output current capacity of up to 13.9 A rms to handle sudden torque demands.
• Compact footprint designed for space-optimized electrical enclosures.
• Built-in protection circuits preventing damage from overvoltage, overcurrent, and thermal overload.

Applications

• Packaging and labeling machinery
• Pick-and-place material handling gantries
• Semiconductor manufacturing tools
• Automated assembly and test systems

Technical Specifications

Installation Guidelines

• Mounting Orientation: Install the drive vertically on a flat, non-flammable panel surface to maximize convection cooling.
• Clearance: Maintain a minimum clearance of 10 mm on either side and 50 mm above and below the drive unit to allow sufficient airflow.
• Grounding: Ensure the drive is solidly connected to the central protective earth (PE) ground busbar to minimize electromagnetic interference (EMI).
• Atmospheric Protection: Verify that the enclosure provides adequate IP rating to protect the drive from dust, conductive particles, and corrosive gases.
