Distributed control architectures requiring resilient, high-speed fiber-optic communications utilize the IP1001-B200 Lightbus fieldbus box to bridge field-level signals with centralized controllers. Designed by Beckhoff, this rugged I/O module integrates directly into the Lightbus ring topology, providing reliable data rates up to 2.5 Mbaud. Its optical fiber physical layer ensures complete immunity to electromagnetic interference (EMI), making it an excellent choice for environments with high electrical noise, such as welding cells or heavy machinery installations.
The IP1001-B200 is housed in a fully sealed enclosure, allowing direct machine mounting without an additional control cabinet. It features a dual-circuit power system that isolates the sensitive control electronics from the field load voltage. System configuration is executed seamlessly via the Beckhoff KS2000 software tool or directly through the master controller, simplifying deployment and diagnostic routines.
| Beckhoff Automation |
| IP1001-B200 |
| 2 x fiber-optic socket for plug ZS1020-0010 |
| 2.5 Mbaud |
| 24 V DC (-15% / +20%) |
| Determined by connected I/O configuration |
| 1 x M8 male connector, 4-pin |
| 1 x M8 female connector, 4-pin |
| Yes (control voltage to fieldbus) |
| approx. 250 g |
| 0 to +55 degC |
| -25 to +85 degC |
| Conforms to EN 60068-2-6 / EN 60068-2-27 |
| Conforms to EN 61000-6-2 / EN 61000-6-4 |
| IP65/66/67 (conforms to EN 60529) |
| Variable (any mounting orientation) |
| CE, UL |
| Connection Type | Interface Description |
|---|---|
| Feed: 24 V DC control voltage input | |
| Downstream: 24 V DC power distribution loop | |
| Lightbus optical receiver channel | |
| Lightbus optical transmitter channel |
When installing the module, ensure the fiber-optic cables are routed to strictly maintain their minimum specified bend radius to prevent signal attenuation or physical damage. Mount the box securely to a flat surface using the integrated mounting holes. For installations requiring IP67 protection, all unused M8 and fiber-optic ports must be sealed using the appropriate protective caps, and mating connectors must be fully torqued according to manufacturer guidelines.
