Description

The Delta ECMA-C11010SS is a high-precision AC servo motor from the industry-leading A2 series, designed to deliver exceptional performance in motion control applications. As part of the ECM (Electrical Commutation Motor) line, this unit is engineered for reliability, high-speed response, and precise positioning accuracy. With a rated output power of 1 kW and a base speed of 3000 r/min, it is well-suited for demanding automation tasks that require consistent torque and dynamic control.

Equipped with a 20-bit incremental encoder, the ECMA-C11010SS provides high-resolution feedback to the servo drive, ensuring smooth operation and precise velocity regulation. The "S" suffix configuration denotes that this model includes a built-in brake and an oil seal, making it robust for industrial environments where maintenance or shaft protection is required. It is designed for standard 220 V systems, ensuring broad compatibility with Delta’s A2 series servo drives.

Features

• Series: A2 Series AC Servo Motor
• Power Rating: 1 kW rated output
• Rated Speed: 3000 r/min
• Voltage: 220 V
• Encoder: 20-bit high-resolution incremental encoder
• Frame Size: 100 mm
• Integrated Protection: Includes electromagnetic brake and oil seal
• Shaft Configuration: Standard shaft with keyway and screw hole

Applications

• Semiconductor manufacturing equipment
• Printing and packaging machinery
• CNC machine tools
• Material handling and robotics
• Automated inspection systems

Technical Specifications

Installation Guidelines

• Mounting: Secure the servo motor to a flat, rigid metal surface to ensure proper heat dissipation and vibration reduction.
• Alignment: Ensure the motor shaft is perfectly aligned with the mechanical load; misalignments can lead to premature bearing failure.
• Brake Operation: The integrated brake is designed for holding and emergency stopping; do not use it for dynamic deceleration unless specified by the controller logic.
• Environment: Protect the motor from direct contact with coolant, lubricants, or heavy dust, even with the oil seal installed.
• Wiring: Use high-quality, shielded cables for the encoder and power connections to prevent signal noise from impacting the 20-bit feedback data.
