Designed for industrial visualization and monitoring, the DOP-112WX operator terminal provides a high-resolution human-machine interface for machine control and factory automation networks. This unit features a 12-inch TFT LCD display designed with a narrow frame profile to maximize active screen space within compact control panels. Equipped with a high-performance Dual Core 1GHz processor, 8GB of Flash ROM, and 1GB of DDR3 RAM, the hardware facilitates rapid graphic rendering, screen transition, and efficient alarm handling.
The interface supports diverse industrial connectivity protocols via dual 100 Mbps Ethernet ports and integrated USB host/slave ports, easing integration with external PLCs and enterprise systems. A robust four-wire resistive touch interface enables dependable input even in demanding factory floor environments where operators may be wearing gloves.
| Manufacturer | Delta Electronics |
| Model/Part Number | DOP-112WX |
| Display Type | 12-inch TFT LCD |
| Color Depth | 24-bit |
| Resolution | 1024 x 768 Pixels |
| Backlight Type | LED Backlight |
| Backlight Brightness | 500 cd/m2 |
| Backlight Lifetime | 50,000 hours |
| Active Display Area | 245.76 mm x 184.32 mm |
| Processor | Dual Core 1GHz |
| Flash ROM | 8 GB |
| System RAM | DDR3 1000MHz 1 GB |
| Touch Panel Type | 4-wire resistive (pressure-sensitive) |
| Ethernet Interface | 2 Ports, 100M bps x 2 |
| USB Ports | 1x Mini USB Slave Ver 2.0, 1x USB Host Ver 2.0 |
| Storage Slot | 1x SD Slot |
| Buzzer | Multi-Tone Frequency (2K Hz to 4K Hz) / 85dB |
| Cooling System | Natural air circulation |
| Operating Voltage | 24 VDC (-15% to +15% allowable range) |
| Voltage Endurance | 500 VAC for 1 minute (between DC24 terminal and FG terminals) |
| Power Consumption | Max. 16.08 W |
| Dimensions (W x H x D) | 317.4 mm x 246.4 mm x 52.7 mm |
| Mounting Cutout Size | 302.7 mm x 228.7 mm |
| Weight | 2110 g |
Ensure the terminal cutout dimensions match the specified 302.7 mm x 228.7 mm panel opening. Insert the HMI through the front of the panel cutout and secure it from the rear using the provided mounting brackets, tightening to the specified torque. Standard DC supply lines must be wired to the 24 VDC terminals, and the Frame Ground (FG) terminal must be directly bonded to the main system ground to prevent electromagnetic interference. Allow sufficient clearance around the back of the enclosure to support natural convective air cooling.
