The KL9540 (KL9540) is a specialized system terminal designed to provide advanced protection for the field supply within a Beckhoff Bus Terminal block. Functioning as a high-efficiency surge filter, this module is engineered to shield sensitive electronic components from overvoltage transients and high-frequency interference present on the 24 VDC field power lines. In heavy industrial sectors such as oil and gas, marine engineering, and power generation, electrical noise and surges can lead to catastrophic hardware failure or signal corruption. The KL9540 acts as a critical line of defense, stabilizing the field potential and ensuring the reliable operation of downstream I/O modules, thereby minimizing unplanned downtime and extending equipment lifespan.
The KL9540 serves as a power conditioning node between the power supply and the field contacts. It supports a robust rated current of up to 10 A, making it capable of handling significant load demands across a large terminal segment. Unlike standard feed-in terminals, the KL9540 integrates specialized filtration circuitry and a dedicated PE (Protective Earth) connection to shunt surge energy safely to the ground.
The module is housed in a compact 12 mm polycarbonate shell and features the standard Beckhoff double-slot and key connection system for seamless side-by-side mounting. It supports pluggable wiring (KS series compatibility) and utilizes spring-actuated terminals, which provide superior vibration resistance compared to traditional screw terminals—a necessity for the DNV GL and ATEX certified environments it is often deployed in.
| Attribute | Specification Details |
| Model | KL9540 |
| Brand | BECKHOFF |
| Function | Surge Filter Field Supply |
| Nominal Voltage | 24 VDC (-15 % / +20 %) |
| Rated Field Current | Max 10 A |
| PE Connection | Yes |
| Wiring Method | Spring Actuation (Screwdriver operated) |
| Wire Range (Solid) | 0.08 to 2.5 mm² (AWG 28-14) |
| Wire Range (Ferrule) | 0.14 to 1.5 mm² (AWG 26-16) |
| Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm |
| Operating Temp | -25 to +60 Celsius |
| Protection Rating | IP20 |
| Approvals | CE, UL, ATEX (Ex nA IIC T4 Gc), DNV GL |
Where should the KL9540 be placed within a Bus Terminal segment?
For maximum protection, the KL9540 should be installed upstream of the I/O modules it is intended to protect. It is typically placed immediately after the bus coupler or a power feed terminal to filter the field supply before it reaches sensitive digital or analog modules.
Does the KL9540 protect the K-bus communication?
No. The KL9540 is specifically designed to filter the field supply (power contacts). It does not filter the internal K-bus logic communication. Protection for logic power is usually handled by the bus coupler's internal filtering or separate logic-side filters.
Can this module be used in hazardous locations?
Yes. The module carries ATEX marking (II 3 G Ex nA IIC T4 Gc), permitting its use in Zone 2 hazardous areas where explosive atmospheres are unlikely to occur but must be accounted for.
PE Termination: The Protective Earth (PE) connection is vital for the surge filter's performance. Ensure a low-impedance connection to the DIN rail. The 35 mm DIN rail must be properly grounded to the cabinet's main earth bar to allow the filter to dissipate transients effectively.
Stripping and Termination: Use a standard flat-head screwdriver to actuate the spring terminals. Ensure a stripping length of 8 to 9 mm. For flexible conductors, using ferrules (f) is highly recommended to prevent fraying and ensure a gas-tight connection under high-vibration conditions.
Current Limitations: While the module is rated for 10 A, always calculate the total simultaneous load of the downstream modules. If the total current exceeds 10 A, an additional power feed terminal must be integrated into the bus assembly.
The KL9540 stands out due to its multi-industry certifications, particularly DNV GL for maritime applications and ATEX for explosive environments. Its polycarbonate housing is not only durable but also fire-retardant. The inclusion of signal LEDs provides immediate visual diagnostic feedback on the status of the field supply. By conforming to EN 61000-6-2/4, the module guarantees that the automation system remains compliant with strict EMC directives, making it a "peace-of-mind" component for complex B2B industrial projects where electrical stability is non-negotiable.
