Siemens 6SL3210-1NE22-6AG1 SINAMICS G120 Power Module

SKU 6SL3210-1NE22-6AG1

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6SL3210-1NE22-6AG1
Origin Germany
Product Type: Power Modules
Barcode: 85044086
Payment: T/T, Western Union
Weight: 5.4 kg
Dimensions: 14.00cm x 16.50cm x 35.50cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

The 6SL3210-1NE22-6AG1 is a SINAMICS G120 Power Module PM230 designed for high-efficiency motor control in industrial pump, fan, and compressor applications. This unit features an integrated Class A filter and offers an IP20 degree of protection. Operating on a 3-phase 380-480 V AC supply, it provides a nominal power rating of 7.5 kW and is optimized for low-overload conditions. It is engineered for modularity, requiring a separate Control Unit such as the CU240B/E-2 or CU230P-2 for operation, and supports firmware versions V4.4 or higher.

Features

Integrated Filtering: Built-in Class A filter for electromagnetic interference suppression.
Robust Protection: IP20 degree of protection for control cabinet installation.
Modular Compatibility: Compatible with CU240B/E-2 and CU230P-2 Control Units.
Overload Capability: Engineered for low-overload (LO) performance (11 kW at 150% for 3 s, 110% for 57 s, 100% for 240 s).
Thermal Management: Operates reliably in ambient temperatures from 0 degC to +40 degC under low-overload conditions.

Applications

Pump systems and centrifugal fans.
Compressor drives in industrial production.
HVAC systems and ventilation control.
Variable torque industrial motion control tasks.

Technical Specifications

Attribute	Specification
Manufacturer	Siemens
Product Range	Sinamics
Subrange	G120
Product Type	Power modules
Main Voltage	380-480 V AC
Input Phases	3
Nominal Power	7.5 kW
Nominal Output Current	26 A
Max. Output Frequency	550 Hz
Max. Output Voltage	550 V
Degree of Protection	IP20
Ambient Temperature	0 to +40 degC (LO)
Dimensions (WxHxD)	14.00 x 16.50 x 35.50 cm
Weight	5.40 kg
Commodity Code	85044086

Installation Guidelines

Mounting: Designed for vertical mounting within a control cabinet. Ensure adequate airflow around the heat sink to meet thermal requirements for the 0-40 degC ambient range.
Control Unit: This Power Module requires a compatible CU240B/E-2 or CU230P-2 Control Unit; ensure the unit is correctly snapped into the module housing.
Firmware: Verify that the connected Control Unit is running firmware version V4.4 or higher to ensure full operational compatibility.
Wiring: Connect power cables according to the rated 26 A output current. Ensure all protective earth (PE) connections are secure.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Does this Power Module include a Control Unit?

No, the Power Module is supplied without a Control Unit; it is released for use with CU240B/E-2 or CU230P-2 units.

What is the primary power rating for this module?

The module has a nominal power rating of 7.5 kW.

What are the ambient temperature limitations for low-overload operation?

The module is designed for operation in ambient temperatures ranging from 0 degC to +40 degC for low-overload (LO) applications.

Is filtering integrated into this unit?

Yes, this unit features an integrated Class A filter.
