330103-02-07-10-02-00 specifies a metric thread, unarmored 3300 XL 8 mm proximity probe used for non-contact machinery displacement measurements. This specific configuration features a metric M10 x 1 thread body without mechanical protective armor, an unthreaded length of 20 mm (Option 02), and an overall case length of 70 mm (Option 07).
With a total length of 1.0 meter (Option 10) and a miniature ClickLoc coaxial connector on standard FEP insulated cable (Option 02), this probe connects directly to a 3300 XL extension cable and Proximitor sensor. Since it features the Option 00 agency approval code, it is intended for general-purpose environments where hazardous area certifications are not required, differentiating it from Option 05 variants.
| Option Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 330103-02-07-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, without armor |
| A - Unthreaded Length | 02 | 20 mm unthreaded length (increments of 10 mm) |
| B - Overall Case Length | 07 | 70 mm case length (increments of 10 mm) |
| C - Total Length | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required / No certifications |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330103-02-07-10-02-00 |
| Product Type | 3300 XL 8 mm Proximity Probe (Metric) |
| Thread Size | M10 x 1 (metric) |
| Armor | Without mechanical protective armor |
| Unthreaded Length | 20 mm |
| Case Length | 70 mm |
| Total Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc (male) |
| Cable Type | 75 ohm triaxial standard cable |
| Cable Insulation | Fluorinated ethylene propylene (FEP) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel |
| Linear Range | 2.0 mm (80 mils), from approximately 0.25 mm (10 mils) to 2.3 mm (90 mils) |
| Nominal Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Probe Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) operating and storage |
| Pressure Seal Limit | Compatible with differential pressure sealing applications (above -34 degC) |
| Tensile Strength | 330 N (75 lbf) maximum rated (probe case to lead) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Dimensions | 150 mm x 150 mm x 40 mm (H x W x D) |
| Weight | 0.14 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-02-07-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 150 mm x 150 mm x 40 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
