Option 02 (0.2 in unthreaded length) and Option 12 (1.2 in case length) specify this 3300 XL 8 mm reverse mount proximity probe configuration — 330105-02-12-10-02-CN. This 3300 XL 8 mm Reverse Mount Proximity Probe is used for non-contacting machinery displacement and vibration measurements when the physical mounting configuration requires installation from the rear or inside of a machine bracket, housing, or sleeve. This design prevents the probe from being pulled or pushed through the mounting hole during operation, providing enhanced mechanical security in heavy industrial installations.
This configuration is equipped with a 1.0 meter (3.3 feet) standard coaxial cable terminating in a miniature male coaxial ClickLoc connector (Option 02). Unlike standard variants which may feature standard North American or European approvals, this specific part number incorporates the -CN suffix, which delivers the China hazardous area approval package. This certification suite covers local Chinese regulatory frameworks, including NEPSI and CCC approvals, certifying the transducer for installation in potentially explosive industrial atmospheres within China.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 330105-02-12-10-02-CN | 3300 XL 8 mm Reverse Mount Probe, 3/8-24 UNF threads |
| A - Unthreaded Length Option | 02 | 0.2 in (5.0 mm) |
| B - Overall Case Length Option | 12 | 1.2 in (30 mm) |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI + CCC + applicable markings) |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number/Model | 330105-02-12-10-02-CN |
| Probe Type | 3300 XL 8 mm Reverse Mount Proximity Probe |
| Thread Type | 3/8-24 UNF-2A threads |
| Unthreaded Length | 0.2 in (5.0 mm) |
| Case Length | 1.2 in (30 mm) |
| Total Length | 1.0 meter (3.3 feet) |
| Cable Type | Standard 75 Ohm coaxial cable (3.68 mm outside diameter) |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Nominal DC Resistance | 7.59 Ohm +/- 0.50 Ohm (center conductor to outer conductor) |
| Linear Range | 2.0 mm (80 mils), starting at approximately 0.25 mm (10 mils) from the probe face |
| System Sensitivity | 7.87 V/mm (200 mV/mil) when paired with 3300 XL Proximitor Sensor |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Probe Pressure Seal | Seals differential pressure up to 7.0 bar (100 psi) between tip and connector |
| Weight | 323 g |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330105-02-12-10-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Reverse Mount Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 323g
Dimensions: 150 mm x 150 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
