Bently Nevada 330130-040-03-05 3300 XL Standard Extension Cable

SKU 330130-040-03-05

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330130-040-03-05
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 410g
Dimensions: 180 mm x 180 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

FEP-insulated armored cable with integrated connector protectors (Option 03) spanning 4.0 m in length (Option 040) — 330130-040-03-05. This 3300 XL standard extension cable connects a 3300 XL 8 mm proximity probe to a 3300 XL Proximitor sensor, establishing a low-loss transmission path for high-frequency eddy-current signals on rotating machinery shafts.

Unlike variants with standard unarmored cabling (Option 00) or those without connector protectors, this configuration uses stainless steel armor wrapped in a fluorinated ethylene propylene (FEP) sheath for high abrasion resistance in harsh mechanical environments. The integrated fluorosilicone connector protectors seal the gold-plated ClickLoc coaxial connections against moisture, oil, and dust, preventing contamination that could degrade signal integrity. Under Option 05, the cable carries hazardous area certificates for global deployment.

Features

Option 040 specifies a 4.0 m (13.1 feet) physical cable length.
Option 03 features stainless steel armor with an FEP outer jacket to protect against physical impact, sharp bends, and environmental wear.
Option 05 provides CSA, ATEX, and IECEx hazardous area approvals.
Pre-installed fluorosilicone connector protectors on the cable ends seal coaxial joints against oil, moisture, and debris.
ClickLoc coaxial connectors feature gold-plated contacts with a finger-tight tactile click latching mechanism that resists loosening under vibration.

Applications

Vibration and position measurement on gas turbines, steam turbines, and large industrial compressors.
High-exposure environments where standard cables risk mechanical abrasion, cutting, or fluid immersion.
Hazardous locations requiring strict explosion-proof or intrinsically safe certifications.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330130-040-03-05	3300 XL Standard Extension Cable, 8 mm system
A - Cable Length Option	040	4.0 meters (13.1 feet)
B - Connector Protector and Cable Option	03	Armored cable with connector protector
C - Agency Approval Option	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer	Bently Nevada
Part Number/Model	330130-040-03-05
Product Family	3300 XL 8 mm Proximity Transducer System
Cable Type	Triaxial, FEP-insulated coaxial cable
Armouring	Stainless steel armor with FEP outer sheath
Cable Length	4.0 m (13.1 ft)
Nominal Core Resistance	0.88 +/- 0.13 Ohm
Nominal Jacket Resistance	0.26 +/- 0.05 Ohm
Extension Cable Capacitance	69.9 pF/m typical
Connector Type	Gold-plated miniature coaxial ClickLoc connectors
Connector Protector Material	Fluorosilicone (female end pre-installed)
Operating and Storage Temperature	-52 degC to +177 degC
Relative Humidity Limit	Less than 3% change in average scale factor in 93% humidity up to 56 days
Weight	0.41 kg
Dimensions	180 mm x 180 mm x 30 mm (H x W x D)

Connections and Interfaces

Connection Point	Connector Type	Function
Male End	Gold-plated miniature coaxial ClickLoc male	Connects to 3300 XL Proximitor Sensor input
Female End	Gold-plated miniature coaxial ClickLoc female	Connects to 3300 XL 8 mm Proximity Probe lead

Installation Guidelines

Do not bend the cable beyond its minimum bend radius of 25.4 mm (1.0 in) for armored sections.
Ensure ClickLoc connectors are joined finger-tight until an audible click is felt; do not use pliers or other tools on gold-plated connectors.
Securely slide the pre-installed connector protectors over the connector joints to isolate the electrical contacts from fluids and casing contact.
Avoid routing proximity sensor extension cables parallel to high-voltage power lines to prevent electromagnetic coupling.

Compliance and Certifications

ATEX/IECEx Zone 0/1/2 hazardous area classification
CSA/FM Class I, Div 1 and Div 2 hazardous locations
CE Mark compliant
RoHS compliant

FAQ

What is the exact physical length of the 330130-040-03-05 extension cable?

This specific cable configuration features a physical length of 4.0 meters (13.1 feet), specified by Option 040.

Does the 330130-040-03-05 model include armor and connector protection?

Yes. Option 03 specifies that this cable comes with stainless steel armor wrapped in an FEP sheath, along with pre-installed fluorosilicone connector protectors.

What hazardous area approvals does this cable carry?

Under Option 05, this cable is certified for hazardous locations with CSA, ATEX, and IECEx approvals.

Can I use this 4.0-meter extension cable with any probe?

It must be paired with a compatible 3300 XL 8 mm proximity probe and Proximitor sensor such that the total system length matches the Proximitor sensor's calibration, typically 5 or 9 meters total.

View all FAQs →

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.
