GT2507-WTBD | Mitsubishi Electric | HMI Série GT25

Description

Designed for demanding industrial visualization tasks, the GT2507-WTBD touch panel serves as a high-performance Human-Machine Interface within the Mitsubishi Electric GT25 Series. Combining cost-efficiency with functional capabilities, this mid-range operator interface features a high-resolution 7-inch widescreen display engineered to optimize operator monitoring and control workflow. Built with a sleek black frame, it integrates seamlessly into modern control cabinets and supports standard 24VDC industrial power networks.

The unit features an analog resistive film touch screen, providing responsive user inputs even in harsh factory environments where operators may wear gloves. The widescreen format offers extra horizontal screen real estate for displaying complex PLC registers, industrial system schematics, and detailed alarm banners, making it a robust interface solution for diverse manufacturing configurations.

Features

• 7-inch wide high-resolution TFT color display for crisp visual representations.
• Analog resistive touch screen allowing versatile, tactile operator inputs.
• Widescreen format (WVGA) providing optimal space for layout designs.
• Industrial black bezel styling tailored for integration into standard control desks and panels.
• Direct 24VDC power supply requirement suitable for typical automation setups.

Applications

• Automotive assembly line monitoring and control systems.
• Packaging machinery control stations.
• Water treatment and chemical dosing management systems.
• Food and beverage production and thermal processing lines.
• General manufacturing automation and conveyor system control.

Technical Specifications

Installation Guidelines

To ensure proper performance and environmental sealing of the GT2507-WTBD HMI panel during operation:

• Prepare a precise panel cutout of 180.5 mm x 133.5 mm into your cabinet door or console.
• Insert the unit through the cutout from the front, ensuring the environmental gasket is seated flush and uncorrupted.
• Secure the display in place using the supplied mounting brackets, applying uniform torque to prevent distortion of the plastic bezel.
• Ensure sufficient ventilation clearance is maintained behind the HMI housing to allow convection cooling.
• Connect the 24VDC power supply line to the dedicated terminal block, verifying polarity before applying electrical power.
